ABM
ABM2500
| Strings | 6 |
|---|---|
| String spacing | 10.4 mm nominal pitch; 52 mm E–E; notch-dependent |
| Mounting / screw / post spacing | 74 mm centers; M5 anchors / 4 mm bearing posts |
| Saddle type | Bell brass; notching required |
| Materials | Bell brass; aluminum/steel body variants |
| Tremolo arm / thread | Not applicable — fixed bridge |
| Radius | 12 in |
| Fitment / other specifications | 2024 guide; verify exact variant. |
Specification sources
Drawings & installation documents
ABM2500-RE
| Strings | 6 |
|---|---|
| String spacing | 10.4 mm nominal pitch; 52 mm E–E; notch-dependent |
| Mounting / screw / post spacing | 73.66–73.81 mm centers; #6-32 rods (earlier M4 versions noted) |
| Saddle type | Bell brass; notching required |
| Materials | Bell brass; aluminum/steel body variants |
| Tremolo arm / thread | Not applicable — fixed bridge |
| Radius | 12 in |
| Fitment / other specifications | 2024 guide; verify exact variant. |
Specification sources
Drawings & installation documents
ABM2504
| Strings | 6 |
|---|---|
| String spacing | 10.4 mm nominal pitch; 52 mm E–E; notch-dependent |
| Mounting / screw / post spacing | 74 mm centers; M5 anchors / 4 mm bearing posts |
| Saddle type | Bell brass; notching required |
| Materials | Bell brass; aluminum/steel body variants |
| Tremolo arm / thread | Not applicable — fixed bridge |
| Radius | 12 in |
| Fitment / other specifications | 2024 guide; verify exact variant. |
Specification sources
Drawings & installation documents
ABM2506
| Strings | 6 |
|---|---|
| String spacing | 10.4 mm nominal pitch; 52 mm E–E; notch-dependent |
| Mounting / screw / post spacing | 82–82.5 mm centers; M8 anchors |
| Saddle type | Bell brass; notching required |
| Materials | Bell brass; aluminum/steel body variants |
| Tremolo arm / thread | Not applicable — fixed bridge |
| Radius | 12 in |
| Fitment / other specifications | 2024 guide; verify exact variant. |
Specification sources
Drawings & installation documents
ABM5050-M
| Strings | 6 |
|---|---|
| String spacing | Source discrepancy: drawing pitch 10.6 mm; prose E–E 2 1/16 in; check original |
| Mounting / screw / post spacing | Six screws; drawing 52.4 mm outer screw centers |
| Saddle type | PVS-S bent steel |
| Materials | Steel plate and block |
| Tremolo arm / thread | Threaded; adjustable DELRIN bushing; thread unspecified |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Do not infer interchangeability from rounded metric/inch equivalents. |
Specification sources
Drawings & installation documents
ABM5050-S
| Strings | 6 |
|---|---|
| String spacing | 10.6 mm pitch; 53 mm E–E |
| Mounting / screw / post spacing | Six screws; 56.35 mm outer screw centers |
| Saddle type | PVS-S bent steel |
| Materials | Steel plate and block |
| Tremolo arm / thread | Threaded; adjustable DELRIN bushing; thread unspecified |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Narrow strings on wide mounting pattern. |
Specification sources
Drawings & installation documents
ABM5050-U
| Strings | 6 |
|---|---|
| String spacing | 53 mm E–E (metric specification) |
| Mounting / screw / post spacing | Two pivots; 56–56.4 mm centers |
| Saddle type | PVS-S bent steel |
| Materials | Steel plate and block |
| Tremolo arm / thread | Threaded; adjustable DELRIN bushing; thread unspecified |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Metric and inch labels differ; use drawing. |
Specification sources
Drawings & installation documents
ABM5050-V
| Strings | 6 |
|---|---|
| String spacing | 11.27 mm pitch; 56.35 mm E–E |
| Mounting / screw / post spacing | Six screws; 56.35 mm outer screw centers |
| Saddle type | PVS-V bent steel |
| Materials | Steel plate and block |
| Tremolo arm / thread | Threaded; adjustable DELRIN bushing; thread unspecified |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Wide vintage pattern. |
Specification sources
Drawings & installation documents
ABM5200
| Strings | 6 |
|---|---|
| String spacing | 53 mm E–E (metric specification; inch label differs) |
| Mounting / screw / post spacing | 56.38 mm post centers |
| Saddle type | Bell brass individual saddles |
| Materials | Bell brass plate; stainless steel block, posts and arm |
| Tremolo arm / thread | Plug-in; adjustable replaceable DELRIN bushing; no screw-in thread |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Replaceable knife edge. Use metric drawing for fitment. |
Specification sources
Drawings & installation documents
ABM5400 Katana (2023 revision)
| Strings | 6 |
|---|---|
| String spacing | 10.7 mm pitch; 53.5 mm E–E |
| Mounting / screw / post spacing | 74–74.5 mm post centers; M7 × 0.75 posts; 10 mm outer-diameter bushings |
| Saddle type | Individual height-adjustable locking saddles |
| Materials | Machined bell brass and steel; hardened steel replaceable knife edge |
| Tremolo arm / thread | Plug-in arm; adjustable socket; no screw-in thread |
| Radius | Individually adjustable saddle heights |
| Fitment / other specifications | 37 mm stock steel block; guide lists 32/42 mm alternatives. Locking nut separate. Check revision-specific routing. |
Specification sources
Drawings & installation documents
Babicz
BabiczFCH 2-Point Trem Narrow — Original Series
| Strings | 6 |
|---|---|
| String spacing | 2-1/16 in E–E |
| Mounting / screw / post spacing | Two-point fulcrum; pivot studs and body inserts supplied |
| Saddle type | eCAM full-contact saddles; side saddle lock |
| Materials | Tempered steel tremolo plate |
| Tremolo arm / thread | Included; thread size not published in cited page |
| Radius | Not published in the cited source |
| Fitment / other specifications | 9.8 oz. Intended for many American Fender two-point guitars; check the official spec sheet before choosing inserts. |
Specification sources
Drawings & installation documents
BabiczFCH Strat Tremolo Narrow — Original Series
| Strings | 6 |
|---|---|
| String spacing | 2-1/16 in E–E |
| Mounting / screw / post spacing | Narrow-spaced Strat-style replacement; verify original six-screw pattern against spec sheet |
| Saddle type | eCAM full-contact saddles; side saddle locking |
| Materials | Not published in the cited source |
| Tremolo arm / thread | Included; thread size not published in cited page |
| Radius | Not published in the cited source |
| Fitment / other specifications | 9.8 oz assembly. “Double locking” in this product description refers to the Original Series saddle design; do not assume Floyd-style string/nut locking. |
Specification sources
Drawings & installation documents
BabiczFCH510G — Babicz by Gotoh
| Strings | 6 |
|---|---|
| String spacing | Not published in the cited source |
| Mounting / screw / post spacing | Two-point fulcrum |
| Saddle type | Babicz patented eCAM full-contact saddles |
| Materials | Heat-treated chromium-molybdenum steel plate; solid steel block |
| Tremolo arm / thread | Not published in the cited source |
| Radius | Not published in the cited source |
| Fitment / other specifications | 12.5 oz. Combines Gotoh 510 platform and Babicz saddles. Do not transfer dimensions or arm threads from a different Gotoh 510 variant without the model drawing. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Bigsby
BigsbyB12
| Strings | 6 |
|---|---|
| String spacing | Bridge E–E string spacing is set by the separate bridge; not specified for this tailpiece. |
| Mounting / screw / post spacing | Archtop electric guitars. Hole dimensions: consult linked blueprint. |
| Saddle type | Separate bridge required; saddle specification belongs to the chosen bridge. |
| Materials | Die-cast aluminum |
| Tremolo arm / thread | Pivoting arm; 1/8-inch Allen key and 5/16-inch socket are adjustment tools, not arm-thread sizes. Thread not specified. |
| Radius | Set by separate bridge. |
| Fitment / other specifications | 212.7 × 92.1 mm; approximately 344 g. |
Specification sources
Drawings & installation documents
BigsbyB16
| Strings | 6 |
|---|---|
| String spacing | Bridge E–E string spacing is set by the separate bridge; not specified for this tailpiece. |
| Mounting / screw / post spacing | Telecaster-style guitars. Hole dimensions: consult linked blueprint. |
| Saddle type | Separate bridge required; saddle specification belongs to the chosen bridge. |
| Materials | Sand-cast aluminum |
| Tremolo arm / thread | Pivoting arm; 1/8-inch Allen key and 5/16-inch socket are adjustment tools, not arm-thread sizes. Thread not specified. |
| Radius | Set by separate bridge. |
| Fitment / other specifications | 212.7 × 107.9 mm; approximately 333 g. |
Specification sources
Drawings & installation documents
BigsbyB3
| Strings | 6 |
|---|---|
| String spacing | Bridge E–E string spacing is set by the separate bridge; not specified for this tailpiece. |
| Mounting / screw / post spacing | Thin hollow and semi-hollow guitars. Hole dimensions: consult linked blueprint. |
| Saddle type | Separate bridge required; saddle specification belongs to the chosen bridge. |
| Materials | Sand-cast aluminum |
| Tremolo arm / thread | Pivoting arm; 1/8-inch Allen key and 5/16-inch socket are adjustment tools, not arm-thread sizes. Thread not specified. |
| Radius | Set by separate bridge. |
| Fitment / other specifications | 193.7 × 92.1 mm; approximately 296 g. |
Specification sources
Drawings & installation documents
BigsbyB5
| Strings | 6 |
|---|---|
| String spacing | Bridge E–E string spacing is set by the separate bridge; not specified for this tailpiece. |
| Mounting / screw / post spacing | Flat-top solidbody guitars; four top-mounting screws. Hole dimensions: consult linked blueprint. |
| Saddle type | Separate bridge required; saddle specification belongs to the chosen bridge. |
| Materials | Aluminum; right-hand die-cast, left-hand sand-cast |
| Tremolo arm / thread | Not documented in the cited manufacturer source. |
| Radius | Set by separate bridge. |
| Fitment / other specifications | 120.65 × 95.3 mm; approximately 287 g. |
Specification sources
Drawings & installation documents
BigsbyB50
| Strings | 6 |
|---|---|
| String spacing | Bridge E–E string spacing is set by the separate bridge; not specified for this tailpiece. |
| Mounting / screw / post spacing | Flat-top guitars. The maker's width in inches and millimetres do not agree; verify blueprint before fitment. Hole dimensions: consult linked blueprint. |
| Saddle type | Separate bridge required; saddle specification belongs to the chosen bridge. |
| Materials | Die-cast aluminum |
| Tremolo arm / thread | Pivoting arm; 1/8-inch Allen key and 5/16-inch socket are adjustment tools, not arm-thread sizes. Thread not specified. |
| Radius | Set by separate bridge. |
| Fitment / other specifications | 109.5 × 94.5 mm; approximately 290 g. |
Specification sources
Drawings & installation documents
BigsbyB6
| Strings | 6 |
|---|---|
| String spacing | Bridge E–E string spacing is set by the separate bridge; not specified for this tailpiece. |
| Mounting / screw / post spacing | Large hollowbody guitars. Hole dimensions: consult linked blueprint. |
| Saddle type | Separate bridge required; saddle specification belongs to the chosen bridge. |
| Materials | Sand-cast aluminum |
| Tremolo arm / thread | Pivoting arm; 1/8-inch Allen key and 5/16-inch socket are adjustment tools, not arm-thread sizes. Thread not specified. |
| Radius | Set by separate bridge. |
| Fitment / other specifications | 235 × 92.1 mm; approximately 311 g. |
Specification sources
Drawings & installation documents
BigsbyB7
| Strings | 6 |
|---|---|
| String spacing | Bridge E–E string spacing is set by the separate bridge; not specified for this tailpiece. |
| Mounting / screw / post spacing | Archtop electric guitars. Hole dimensions: consult linked blueprint. |
| Saddle type | Separate bridge required; saddle specification belongs to the chosen bridge. |
| Materials | Aluminum; right-hand die-cast, left-hand sand-cast |
| Tremolo arm / thread | Pivoting arm; 1/8-inch Allen key and 5/16-inch socket are adjustment tools, not arm-thread sizes. Thread not specified. |
| Radius | Set by separate bridge. |
| Fitment / other specifications | 222.3 × 92.1 mm; approximately 354 g. |
Specification sources
Drawings & installation documents
BigsbyB70
| Strings | 6 |
|---|---|
| String spacing | Bridge E–E string spacing is set by the separate bridge; not specified for this tailpiece. |
| Mounting / screw / post spacing | Archtop electric guitars. Hole dimensions: consult linked blueprint. |
| Saddle type | Separate bridge required; saddle specification belongs to the chosen bridge. |
| Materials | Die-cast aluminum |
| Tremolo arm / thread | Pivoting arm; 1/8-inch Allen key and 5/16-inch socket are adjustment tools, not arm-thread sizes. Thread not specified. |
| Radius | Set by separate bridge. |
| Fitment / other specifications | 220.7 × 95.3 mm; approximately 358 g. |
Specification sources
Drawings & installation documents
Callaham
CallahamAmerican Standard Hardtail — Bigsby relief
| Strings | 6 |
|---|---|
| String spacing | 2 1/16 inches E–E |
| Mounting / screw / post spacing | American Standard hardtail pattern, explicitly different from vintage hardtail; exact screw spacing not stated. |
| Saddle type | Three compensated brass Bigsby saddles; bridge relief for vibrato use. |
| Materials | Saddle material stated above; plate alloy not specified in this listing. |
| Tremolo arm / thread | Not applicable; Bigsby variant uses a separate vibrato. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
CallahamAmerican Standard Hardtail — compensated
| Strings | 6 |
|---|---|
| String spacing | 2 1/16 inches E–E |
| Mounting / screw / post spacing | American Standard hardtail pattern, explicitly different from vintage hardtail; exact screw spacing not stated. |
| Saddle type | Three compensated brass saddles. |
| Materials | Saddle material stated above; plate alloy not specified in this listing. |
| Tremolo arm / thread | Not applicable; Bigsby variant uses a separate vibrato. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
CallahamAmerican Standard Hardtail — six saddle
| Strings | 6 |
|---|---|
| String spacing | 2 1/16 inches E–E |
| Mounting / screw / post spacing | American Standard hardtail pattern, explicitly different from vintage hardtail; exact screw spacing not stated. |
| Saddle type | Six narrow vintage CG saddles. |
| Materials | Saddle material stated above; plate alloy not specified in this listing. |
| Tremolo arm / thread | Not applicable; Bigsby variant uses a separate vibrato. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
CallahamMexican Standard Model Strat Assembly
| Strings | 6 |
|---|---|
| String spacing | 2 1/16 inches E–E |
| Mounting / screw / post spacing | Six pivots; 2 1/16 inches outside screw spacing; 1 3/4-inch body and vintage routing required. |
| Saddle type | Six stamped steel CG saddles; stainless adjustment hardware. |
| Materials | Cold-rolled steel block; machined top plate. |
| Tremolo arm / thread | 10-32 English thread; supplied virtual pop-in arm supported by a Delrin bushing. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Manufacturer lists the complete assembly as discontinued in 2026. |
Specification sources
Drawings & installation documents
CallahamV/N Model Strat Assembly
| Strings | 6 |
|---|---|
| String spacing | 2 1/16 inches E–E (maker rounds to 52 mm) |
| Mounting / screw / post spacing | Six pivots; 2 7/32 inches outside screw spacing (maker rounds to 56 mm). |
| Saddle type | Six stamped steel CG saddles; stainless adjustment hardware. |
| Materials | Cold-rolled steel block; machined top plate. |
| Tremolo arm / thread | 10-32 English thread; supplied virtual pop-in arm supported by a Delrin bushing. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
CallahamVintage Hardtail
| Strings | 6 |
|---|---|
| String spacing | 2 7/32 inches E–E |
| Mounting / screw / post spacing | Vintage hardtail pattern; three plate screws supplied. Screw-centre dimensions not specified. |
| Saddle type | Six stamped steel CG saddles. |
| Materials | Machined plate; stainless adjustment screws and springs. |
| Tremolo arm / thread | Not applicable. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
CallahamVintage S Model Strat Assembly
| Strings | 6 |
|---|---|
| String spacing | 2 7/32 inches E–E |
| Mounting / screw / post spacing | Six pivots; 2 7/32 inches between outside mounting screw centres. |
| Saddle type | Six stamped steel CG saddles; stainless adjustment hardware. |
| Materials | Cold-rolled steel block; machined top plate. |
| Tremolo arm / thread | 10-32 English thread; supplied virtual pop-in arm supported by a Delrin bushing. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
Duesenberg
Duesenberg3-Point Radius Bridge HWD3
| Strings | 6 |
|---|---|
| String spacing | 52 mm E–E |
| Mounting / screw / post spacing | 73.5 mm stud centres; M4 studs, bushings and three-step thumbwheels supplied. |
| Saddle type | Sintered steel; three contact points per saddle. |
| Materials | Sintered steel saddles; body alloy not specified. |
| Tremolo arm / thread | Not applicable. |
| Radius | Maker describes a curved top but does not specify numeric radius on cited page. |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
DuesenbergDiamond Deluxe Tremola — Short
| Strings | 6 |
|---|---|
| String spacing | Set by separate bridge; not stated at axle. |
| Mounting / screw / post spacing | Top mount; four 3.5 × 32 mm screws supplied. Hole-centre distances not listed. |
| Saddle type | Separate bridge required. |
| Materials | Needle and nylon bearings; frame alloy not stated in cited short-model listing. |
| Tremolo arm / thread | Round insert arm held by two grub screws; adjustable height/length. Holder uses 5 mm threaded locking stem; arm itself is not screw-in. |
| Radius | Set by separate bridge. |
| Fitment / other specifications | For flat-top solidbody guitars; ensure mounting screws engage wood fully. |
Specification sources
Drawings & installation documents
DuesenbergLes Trem II
| Strings | 6 |
|---|---|
| String spacing | Set by separate Tune-o-matic bridge. |
| Mounting / screw / post spacing | 81.5 mm mounting bolt centres; supplied M8 and US-thread mounting bolts (US pitch unspecified). |
| Saddle type | Uses existing separate Tune-o-matic bridge. |
| Materials | Not documented in the cited manufacturer source. |
| Tremolo arm / thread | Inserted arm secured by two grub screws; rotation set by locknut. Not a screw-in arm. |
| Radius | Set by existing bridge. |
| Fitment / other specifications | Check top clearance and use supplied washers when needed. |
Specification sources
Drawings & installation documents
DuesenbergWrap-Around HW01 (81.5 mm)
| Strings | 6 |
|---|---|
| String spacing | 52 mm E–E |
| Mounting / screw / post spacing | 81.5 mm bolt centres; metric studs supplied. |
| Saddle type | Forged steel, individually adjustable. |
| Materials | Brass body; steel saddles. |
| Tremolo arm / thread | Not applicable. |
| Radius | Maker wholesaler lists 14 inches; Duesenberg shop describes suitability for 12–14-inch boards. |
| Fitment / other specifications | 15 mm centre height from bottom edge to saddle notch. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
DuesenbergWrap-Around HW06 (74 mm shop version)
| Strings | 6 |
|---|---|
| String spacing | Not documented in the cited manufacturer source. |
| Mounting / screw / post spacing | 74 mm stud centres according to Duesenberg shop; conversion from Tune-o-matic requires enlarging holes. |
| Saddle type | Forged steel. |
| Materials | Not documented in the cited manufacturer source. |
| Tremolo arm / thread | Not applicable. |
| Radius | Suitable for 12–14-inch fingerboards. |
| Fitment / other specifications | The wholesaler names HW06 as 73.5 mm while the Duesenberg shop says 74 mm. Verify current drawing and physical unit; do not treat as guaranteed drop-in. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Evertune
EvertuneF Model
| Strings | 6 |
|---|---|
| String spacing | Approximately 0.41 in / 10.4 mm per adjacent string; floating saddles allow slight variation |
| Mounting / screw / post spacing | Routed body installation; faceplate and footplate. No conventional pivot post spacing. |
| Saddle type | Independent mechanical constant-tension saddle modules |
| Materials | Not published in the cited source |
| Tremolo arm / thread | Not applicable — constant-tension fixed bridge |
| Radius | Not published in the cited source |
| Fitment / other specifications | For lower bridge string heights; substantial custom routing required. |
Specification sources
Drawings & installation documents
EvertuneF7
| Strings | 7 |
|---|---|
| String spacing | Approximately 0.41 in / 10.4 mm per adjacent string; floating saddles allow slight variation |
| Mounting / screw / post spacing | Routed body installation; faceplate and footplate. No conventional pivot post spacing. |
| Saddle type | Independent mechanical constant-tension saddle modules |
| Materials | Not published in the cited source |
| Tremolo arm / thread | Not applicable — constant-tension fixed bridge |
| Radius | Not published in the cited source |
| Fitment / other specifications | F7 is 10.4 mm wider than F6. Use the seven-string routing file. |
Specification sources
Drawings & installation documents
EvertuneF8
| Strings | 8 |
|---|---|
| String spacing | Approximately 0.41 in / 10.4 mm per adjacent string; floating saddles allow slight variation |
| Mounting / screw / post spacing | Routed body installation; faceplate and footplate. No conventional pivot post spacing. |
| Saddle type | Independent mechanical constant-tension saddle modules |
| Materials | Not published in the cited source |
| Tremolo arm / thread | Not applicable — constant-tension fixed bridge |
| Radius | Not published in the cited source |
| Fitment / other specifications | F8 is 20.8 mm wider than F6. Use the eight-string routing file. |
Specification sources
Drawings & installation documents
EvertuneG Model Long
| Strings | 6 |
|---|---|
| String spacing | Approximately 0.41 in / 10.4 mm per adjacent string; floating saddles allow slight variation |
| Mounting / screw / post spacing | Routed body installation; faceplate and footplate. No conventional pivot post spacing. |
| Saddle type | Independent mechanical constant-tension saddle modules |
| Materials | Not published in the cited source |
| Tremolo arm / thread | Not applicable — constant-tension fixed bridge |
| Radius | Not published in the cited source |
| Fitment / other specifications | Extended faceplate often requires trimming to bridge pickup bezel. |
Specification sources
EvertuneG Model Standard
| Strings | 6 |
|---|---|
| String spacing | Approximately 0.41 in / 10.4 mm per adjacent string; floating saddles allow slight variation |
| Mounting / screw / post spacing | Routed body installation; faceplate and footplate. No conventional pivot post spacing. |
| Saddle type | Independent mechanical constant-tension saddle modules |
| Materials | Not published in the cited source |
| Tremolo arm / thread | Not applicable — constant-tension fixed bridge |
| Radius | Not published in the cited source |
| Fitment / other specifications | Raised-bridge applications; choose using manufacturer bridge-height and pickup-position guidance. |
Specification sources
EvertuneT Model
| Strings | 6 |
|---|---|
| String spacing | Approximately 0.41 in / 10.4 mm per adjacent string; floating saddles allow slight variation |
| Mounting / screw / post spacing | Routed body installation; faceplate and footplate. No conventional pivot post spacing. |
| Saddle type | Independent mechanical constant-tension saddle modules |
| Materials | Not published in the cited source |
| Tremolo arm / thread | Not applicable — constant-tension fixed bridge |
| Radius | Not published in the cited source |
| Fitment / other specifications | F-type mechanism with Tele-style pickup-surround faceplate. |
Specification sources
Drawings & installation documents
Fender
Fender6-Saddle American Series Telecaster Bridge
| Strings | 6 |
|---|---|
| String spacing | 2-3/16 inches E–E. |
| Mounting / screw / post spacing | Not documented in the sources reviewed. |
| Saddle type | Six individually adjustable saddles; offset intonation screws. |
| Materials | Material alloy not stated in reviewed listing. |
| Tremolo arm / thread | Not applicable: fixed bridge. |
| Radius | Individual saddle height adjustment. |
| Fitment / other specifications | String-through-body design; listed for American, American Deluxe and American Standard Telecasters made 1986–2007. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
FenderAmerican Series Strat Tremolo Assembly (86–07)
| Strings | 6 |
|---|---|
| String spacing | 2-1/16 inches E–E. |
| Mounting / screw / post spacing | 2-7/32 inches mounting spacing. |
| Saddle type | Powder-coated steel block saddles; offset intonation screws. |
| Materials | Steel saddles; block alloy not specified in reviewed listing. |
| Tremolo arm / thread | Screw-in; exact thread not documented in reviewed listing. |
| Radius | Individual saddle height adjustment. |
| Fitment / other specifications | Listed for most American and American Standard Stratocasters made 1986–2007. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
FenderAmerican Standard Strat Tremolo Assembly (08–present)
| Strings | 6 |
|---|---|
| String spacing | 2-1/16 inches E–E. |
| Mounting / screw / post spacing | Two-post mounting; 2-7/32 inches centers. |
| Saddle type | Fender-stamped bent-steel saddles. |
| Materials | Cold-rolled steel tremolo block; chrome assembly. |
| Tremolo arm / thread | Screw-in; exact thread not documented in reviewed listing. |
| Radius | Individual saddle height adjustment. |
| Fitment / other specifications | Keep separate from 1986–2007 version with offset intonation screws. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
FenderAmerican Vintage Hardtail Strat Bridge
| Strings | 6 |
|---|---|
| String spacing | Listed only as vintage-style; exact dimension not documented in reviewed source. |
| Mounting / screw / post spacing | Three-screw mounting; exact hole centers not documented. |
| Saddle type | Six nickel-plated Fender-stamped saddles. |
| Materials | Nickel-plated steel bridge plate. |
| Tremolo arm / thread | Not applicable: fixed bridge. |
| Radius | Individual saddle height adjustment. |
| Fitment / other specifications | String-through-body. Also listed for certain 72 Thinline/Deluxe and Cabronita Telecasters; mounting screws not included. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
FenderDeluxe Series 2-Point Tremolo Assembly
| Strings | 6 |
|---|---|
| String spacing | 2-1/16 inches E–E. |
| Mounting / screw / post spacing | Two-post mounting; 2-7/32 inches post spacing. |
| Saddle type | Fender-stamped bent-steel saddles. |
| Materials | Steel tremolo block; chrome assembly. |
| Tremolo arm / thread | Screw-in; exact thread not documented in reviewed listing. |
| Radius | Individual saddle height adjustment. |
| Fitment / other specifications | Manufacturer lists most Player, Deluxe, Classic Player and Vintera Modified Stratocasters; confirm cavity and exact model before swapping. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
FenderPure Vintage Strat Tremolo Assembly
| Strings | 6 |
|---|---|
| String spacing | 2-7/32 inches E–E. |
| Mounting / screw / post spacing | 2-7/32 inches mounting spacing. |
| Saddle type | Fender Pat. Pend.-stamped saddles; alloy not specified in reviewed listing. |
| Materials | Nickel finish; block alloy not specified in reviewed listing. |
| Tremolo arm / thread | Thread specification unresolved: current Fender listing prints an ambiguous “3-16”; confirm with Fender rather than treat it as a verified fastener standard. |
| Radius | Individual saddle height adjustment. |
| Fitment / other specifications | Used on American Vintage 56, 59 and 65 Stratocaster models. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
FenderVintage-Style Standard Series Strat Tremolo (06–present)
| Strings | 6 |
|---|---|
| String spacing | 2-1/16 inches E–E. |
| Mounting / screw / post spacing | Six-screw mount; 2-1/16 inches outer mounting-hole spacing. |
| Saddle type | Fender-stamped bent-steel saddles. |
| Materials | Cast-zinc tremolo block; chrome assembly. |
| Tremolo arm / thread | M5 × 0.8 threaded arm; arm not included. |
| Radius | Independent saddle heights; M4 × 0.5 height screws. |
| Fitment / other specifications | Metric hardware. Claw, springs and mounting hardware are not included. Fender also prints 2.065 inches for mounting; retain nominal fraction rather than assuming decimal precision. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
FenderVintage/Narrow Strat Tremolo Assembly
| Strings | 6 |
|---|---|
| String spacing | 2-1/16 inches E–E. |
| Mounting / screw / post spacing | Six-screw mounting; 2-7/32 inches outer mounting-hole spacing. |
| Saddle type | Bent nickel-plated steel Fender-stamped saddles. |
| Materials | Cold-rolled steel tremolo block; chrome assembly. |
| Tremolo arm / thread | 10-32 threaded arm. |
| Radius | Individual saddle height adjustment. |
| Fitment / other specifications | Combines vintage mounting width with modern string spread. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Fishman
FishmanPowerbridge AST
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Four mounting holes, 7/64 in (2.8 mm) diameter per template; use full drawing for offsets. |
| Saddle type | Piezo pickup bridge system; saddle alloy not documented in cited sources. |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | Not applicable — fixed bridge. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Modern American Standard Telecaster pickup-location format; distinct from VT. Separate string grounding is required. Powerchip preamp is recommended but optional. |
Specification sources
FishmanPowerbridge TSV
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Two studs; official template shows 2.188 in (55.57 mm) pivot centres and 11/32 in (8.73 mm) holes. |
| Saddle type | Piezo pickup bridge system; saddle alloy not documented in cited sources. |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | Arm attachment / thread size not documented in cited sources. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | American Standard Strat replacement format; listed as a past product. Separate string grounding is required. Powerchip preamp is recommended but optional. |
Specification sources
FishmanPowerbridge Tune-O-Matic
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Post centres 2.935 in (74.55 mm); template calls for .272 in I-drill (7 mm). |
| Saddle type | Piezo pickup bridge system; saddle alloy not documented in cited sources. |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | Not applicable — fixed bridge. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Nashville footprint. Fishman warns that replacing ABR-1 requires different post-hole work. Separate string grounding is required. Powerchip preamp is recommended but optional. |
Specification sources
FishmanPowerbridge VMV
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Six-screw mount. Template row: 2.220 in (56.38 mm) overall; five .444 in (11.29 mm) intervals. |
| Saddle type | Piezo pickup bridge system; saddle alloy not documented in cited sources. |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | Arm attachment / thread size not documented in cited sources. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Vintage Strat six-screw replacement format; listed as a past product. Separate string grounding is required. Powerchip preamp is recommended but optional. |
Specification sources
FishmanPowerbridge VS-50 / VS-50P
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Wilkinson-style two-stud mount; centre spacing not transcribed from drawing. |
| Saddle type | Piezo pickup bridge system; saddle alloy not documented in cited sources. |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | Arm attachment / thread size not documented in cited sources. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Wilkinson-style Strat replacement format; use the linked routing guide for exact dimensions. Separate string grounding is required. Powerchip preamp is recommended but optional. |
Specification sources
FishmanPowerbridge VT
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Four mounting holes, 7/64 in (2.8 mm) diameter per template; use full drawing for offsets. |
| Saddle type | Piezo pickup bridge system; saddle alloy not documented in cited sources. |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | Not applicable — fixed bridge. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Vintage T-style replacement format. Separate string grounding is required. Powerchip preamp is recommended but optional. |
Specification sources
Floyd Rose
Floyd Rose1000 Series Original Style
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm pitch in official model drawing. |
| Mounting / screw / post spacing | Two pivot studs; 74 mm centers in official model drawing. |
| Saddle type | Hardened-steel locking saddles. |
| Materials | Hardened-steel baseplate; 37 mm nickel-plated brass block. |
| Tremolo arm / thread | Screw-on cap, stainless steel; thread pitch not listed. |
| Radius | 12 inches. |
| Fitment / other specifications | Made in Korea. Current product page offers direct aftermarket sales; older OEM-only descriptions are outdated. |
Specification sources
Drawings & installation documents
Floyd Rose1000 Series Pro 6-String
| Strings | 6 |
|---|---|
| String spacing | 0.420 inch pitch in description; drawing labels 10.67 mm. |
| Mounting / screw / post spacing | Two pivot studs; drawing labels 73.91 mm centers. |
| Saddle type | Hardened-steel locking saddles. |
| Materials | Hardened-steel baseplate; 37 mm nickel-plated brass block. |
| Tremolo arm / thread | Screw-on cap, stainless steel; thread pitch not listed. |
| Radius | 12 inches. |
| Fitment / other specifications | Low profile. Its floating route differs from Original; German Pro uses narrower spacing and is a different model. Made in Korea. |
Specification sources
Drawings & installation documents
Floyd Rose1000 Series Pro 7-String
| Strings | 7 |
|---|---|
| String spacing | 0.420 inch per string in manufacturer description. |
| Mounting / screw / post spacing | Two mounting studs; exact centers not transcribed from linked drawing. |
| Saddle type | Hardened-steel locking saddles. |
| Materials | Hardened-steel baseplate; 37 mm nickel-plated brass block. |
| Tremolo arm / thread | Screw-on cap, stainless steel; thread pitch not listed. |
| Radius | 12 inches (current product listing). |
| Fitment / other specifications | Low-profile seven-string model; keep separate from Original seven-string, whose current listed radius is 20 inches. |
Specification sources
Drawings & installation documents
Floyd RoseNon-Fine Tuner
| Strings | 6 |
|---|---|
| String spacing | 10.80 mm pitch in official drawing. |
| Mounting / screw / post spacing | Wood mounting screws; 74.00 mm centers. |
| Saddle type | Locking saddles, without bridge fine tuners. |
| Materials | Hardened steel; block alloy not specified in reviewed listing. |
| Tremolo arm / thread | Vintage screw-in; thread pitch not specified. |
| Radius | Not documented in the sources reviewed. |
| Fitment / other specifications | Official drawing: 94.00 mm overall width, 14.00 mm bridge height. Locking nut sold separately. |
Specification sources
Drawings & installation documents
Floyd RoseOriginal 7-String
| Strings | 7 |
|---|---|
| String spacing | 10.8 mm pitch; 64.8 mm outer-string spread. |
| Mounting / screw / post spacing | Two pivot studs; 85.1 mm centers. |
| Saddle type | CNC-machined hardened-steel locking saddles. |
| Materials | Hardened-steel baseplate; 37 mm nickel-plated brass block. |
| Tremolo arm / thread | Screw-on cap, stainless steel; thread pitch not listed. |
| Radius | 20 inches (current product listing). |
| Fitment / other specifications | Locking nut included in listed kit; do not use six-string routing or post spacing. |
Specification sources
Drawings & installation documents
Floyd RoseOriginal Limited 1984
| Strings | 6 |
|---|---|
| String spacing | 10.7 mm per string in the dimension sheet linked by this model. |
| Mounting / screw / post spacing | Two wood mounting screws; 74 mm centers in linked dimension sheet. |
| Saddle type | CNC-machined hardened-steel locking saddles. |
| Materials | Hardened-steel baseplate; 37 mm fat brass sustain block. |
| Tremolo arm / thread | Vintage screw-in stainless-steel arm; thread pitch not listed. |
| Radius | 12 inches. |
| Fitment / other specifications | Exposed brass fine tuners; locking nut sold separately. This model links the older dimension sheet, not the 2021 Original drawing. |
Specification sources
Drawings & installation documents
Floyd RoseOriginal Tremolo System
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm per string; 54 mm E–E (2021 schematic). |
| Mounting / screw / post spacing | Two pivot studs; 74.3 mm centers (2021 schematic). |
| Saddle type | CNC-machined hardened-steel locking saddles. |
| Materials | Hardened-steel baseplate; 37 mm nickel-plated brass block. |
| Tremolo arm / thread | Stainless steel; screw-on cap. Thread pitch not specified. |
| Radius | 12 inches (current product listing). |
| Fitment / other specifications | Use the linked revision: older official drawing uses 10.7 mm pitch and 74 mm centers. Do not treat drawing revisions as identical. |
Specification sources
Drawings & installation documents
Floyd RoseRail Tail Narrow
| Strings | 6 |
|---|---|
| String spacing | 2-1/16 inches E–E; spec sheet rounds to 52 mm. |
| Mounting / screw / post spacing | Universal rail secured with four screws; pitch not specified in reviewed text. |
| Saddle type | Roller-fitted string saddles. |
| Materials | Not documented in the sources reviewed. |
| Tremolo arm / thread | Arm thread not specified in reviewed sources. |
| Radius | Not documented in the sources reviewed. |
| Fitment / other specifications | Dive-only. Intended for six-point Strat-style bodies; two-point bodies require drilling. Narrow and wide plates interchange on the same rail. |
Specification sources
Drawings & installation documents
Floyd RoseRail Tail Wide
| Strings | 6 |
|---|---|
| String spacing | 2-7/32 inches E–E; spec sheet rounds to 56 mm. |
| Mounting / screw / post spacing | Universal rail secured with four screws; pitch not specified in reviewed text. |
| Saddle type | Roller-fitted string saddles. |
| Materials | Not documented in the sources reviewed. |
| Tremolo arm / thread | Arm thread not specified in reviewed sources. |
| Radius | Not documented in the sources reviewed. |
| Fitment / other specifications | Dive-only. Intended for six-point Strat-style bodies; two-point bodies require drilling. Narrow and wide plates interchange on the same rail. |
Specification sources
Drawings & installation documents
Floyd RoseSpecial Tremolo System
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm per string in official drawing. |
| Mounting / screw / post spacing | Two pivot studs; 74 mm centers. |
| Saddle type | Zinc-alloy locking saddles. |
| Materials | Spot-hardened steel baseplate; 37 mm zinc-alloy stock block. |
| Tremolo arm / thread | Screw-on cap, stainless steel; thread pitch not listed. |
| Radius | 12 inches. |
| Fitment / other specifications | Drawing also lists variable block heights of 32, 34, 36, 37 and 42 mm; order-specific block must be checked. |
Specification sources
Drawings & installation documents
FU Tone
FU ToneFU2 Build Your Own Bridge Tremolo
| Strings | 6 / 7 |
|---|---|
| String spacing | Not documented in the sources reviewed. |
| Mounting / screw / post spacing | Post options offered; center spacing not documented in reviewed listing. |
| Saddle type | Standard, titanium or GraphTech String Saver saddle choices. |
| Materials | Brass/copper/titanium block choices, 32 / 37 / 42 mm. Hardware, inserts and claw material depend on chosen configuration. |
| Tremolo arm / thread | Standard, wrench-tip or push-in options described; thread size not specified. |
| Radius | Not documented in the sources reviewed. |
| Fitment / other specifications | Custom configured model: record the selected block, saddles, inserts and arm; one universal material specification would be misleading. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
G&L
G&LDual-Fulcrum Vibrato (USA forged-brass-saddle version)
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Two knife-edge pivot bolts in brass body inserts; post spacing unspecified. |
| Saddle type | Forged brass saddles on cited USA Legacy version. |
| Materials | Hardened steel plate; heat-treated cold-rolled steel bolts; brass inserts; aluminum arm. |
| Tremolo arm / thread | Machined aluminum arm retained by an Allen screw bearing on a nylon insert. Threaded-arm size not applicable to this retention method. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | USA forged-brass-saddle specification is not assumed for every Tribute or historical G&L variant. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
G&LSaddle-Lock Guitar Bridge (forged-brass-saddle version)
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Base underside protrusion engages a body route; drilling layout unspecified. |
| Saddle type | Forged brass saddles on cited Espada version. |
| Materials | Brass saddles; other alloys not documented in cited sources. |
| Tremolo arm / thread | Not applicable — fixed bridge. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | This record is for the guitar bridge; bass Saddle-Lock spacings must not be substituted. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Gibson
GibsonNashville Tune-O-Matic OEM replacement
| Strings | 6 |
|---|---|
| String spacing | Unnotched saddles; final string layout requires saddle notching. Nominal spacing not listed. |
| Mounting / screw / post spacing | Exact stud centre spacing and thread not listed in this OEM source. |
| Saddle type | Unnotched; individual saddle-screw retaining clips; wider body for additional intonation travel. |
| Materials | Not specified; chrome, nickel and gold are finish options, not body alloys. |
| Tremolo arm / thread | Not applicable. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Do not assume dimensions from an aftermarket Nashville-compatible bridge apply to this OEM part. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Gotoh
Gotoh510FB
| Strings | 6 |
|---|---|
| String spacing | 10.5 mm adjacent-string pitch; 52.5 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Two posts, 74 mm centre-to-centre (manufacturer drawing); M8 studs, 11.3 mm diameter inserts |
| Saddle type | Brass |
| Materials | Brass saddles; base alloy not stated on reviewed page |
| Tremolo arm / thread | Not applicable (fixed bridge) |
| Radius | 350 mm |
| Fitment / other specifications | Stud-lock system |
Specification sources
Drawings & installation documents
Gotoh510T-BS1
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent-string pitch; 54 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Two pivot posts, 56 mm centre-to-centre; M6 studs with 10 mm diameter inserts (manufacturer drawing) |
| Saddle type | Brass |
| Materials | Chromium-molybdenum steel baseplate (510 series); brass saddles; block alloy not specified on model page |
| Tremolo arm / thread | A7 arm, 5.5 mm shaft diameter; thread pitch not specified in reviewed sources (shaft diameter is not a thread size) |
| Radius | Not documented in reviewed manufacturer sources |
| Fitment / other specifications | Block height options: 37mm or 42mm; FST string-path mechanism shown in model drawing |
Specification sources
Drawings & installation documents
Gotoh510T-FE1
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent-string pitch; 54 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Two pivot posts, 56 mm centre-to-centre; M6 studs with 10 mm diameter inserts (manufacturer drawing) |
| Saddle type | Steel |
| Materials | Chromium-molybdenum steel baseplate (510 series); steel saddles; block alloy not specified on model page |
| Tremolo arm / thread | A7 arm, 5.5 mm shaft diameter; thread pitch not specified in reviewed sources (shaft diameter is not a thread size) |
| Radius | Not documented in reviewed manufacturer sources |
| Fitment / other specifications | Block height options: 37mm or 42mm; FST string-path mechanism shown in model drawing |
Specification sources
Drawings & installation documents
Gotoh510T-FE2
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent-string pitch; 54 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Six pivot screws: 56 mm outer screw centres, 11.2 mm screw pitch (manufacturer drawing) |
| Saddle type | Steel |
| Materials | Chromium-molybdenum steel baseplate (510 series); steel saddles; block alloy not specified on model page |
| Tremolo arm / thread | A7 arm, 5.5 mm shaft diameter; thread pitch not specified in reviewed sources (shaft diameter is not a thread size) |
| Radius | Not documented in reviewed manufacturer sources |
| Fitment / other specifications | Block height options: 37mm or 42mm; FST string-path mechanism shown in model drawing |
Specification sources
Drawings & installation documents
Gotoh510TS-BS1
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent-string pitch; 54 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Two pivot posts, 56 mm centre-to-centre; M6 studs with 10 mm diameter inserts (manufacturer drawing) |
| Saddle type | Brass |
| Materials | Chromium-molybdenum steel baseplate (510 series); brass saddles; steel block |
| Tremolo arm / thread | A7 arm, 5.5 mm shaft diameter; thread pitch not specified in reviewed sources (shaft diameter is not a thread size) |
| Radius | Not documented in reviewed manufacturer sources |
| Fitment / other specifications | Block height options: 37mm or 42mm |
Specification sources
Drawings & installation documents
Gotoh510TS-FE1
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent-string pitch; 54 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Two pivot posts, 56 mm centre-to-centre; M6 studs with 10 mm diameter inserts (manufacturer drawing) |
| Saddle type | Steel |
| Materials | Chromium-molybdenum steel baseplate (510 series); steel saddles; steel block |
| Tremolo arm / thread | A7 arm, 5.5 mm shaft diameter; thread pitch not specified in reviewed sources (shaft diameter is not a thread size) |
| Radius | Not documented in reviewed manufacturer sources |
| Fitment / other specifications | Block height options: 37mm or 42mm |
Specification sources
Drawings & installation documents
Gotoh510TS-FE2
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent-string pitch; 54 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Six pivot screws: 56 mm outer screw centres, 11.2 mm screw pitch (manufacturer drawing) |
| Saddle type | Steel |
| Materials | Chromium-molybdenum steel baseplate (510 series); steel saddles; steel block |
| Tremolo arm / thread | A7 arm, 5.5 mm shaft diameter; thread pitch not specified in reviewed sources (shaft diameter is not a thread size) |
| Radius | Not documented in reviewed manufacturer sources |
| Fitment / other specifications | Block height options: 37mm or 42mm |
Specification sources
Drawings & installation documents
Gotoh510UB
| Strings | 6 |
|---|---|
| String spacing | 10.4 mm adjacent-string pitch; 52 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Two posts, 82 mm centre-to-centre (manufacturer drawing); M8 studs, 11.3 mm diameter inserts |
| Saddle type | Hard Zinc |
| Materials | Hard Zinc saddles; base alloy not stated on reviewed page |
| Tremolo arm / thread | Not applicable (fixed bridge) |
| Radius | 350 mm |
| Fitment / other specifications | Stud-lock system |
Specification sources
Drawings & installation documents
GotohGE101T
| Strings | 6 |
|---|---|
| String spacing | 11.3 mm adjacent-string pitch; 56.5 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Six pivot screws: 56 mm outer screw centres, 11.2 mm screw pitch (manufacturer drawing) |
| Saddle type | Steel (Sheet Metal) |
| Materials | Sheet-steel saddles; block alloy not stated on reviewed page |
| Tremolo arm / thread | A1/A2 arm; A1 shaft diameter 5 mm; thread pitch not specified on reviewed page |
| Radius | Not documented in reviewed manufacturer sources |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
GotohGE101TS
| Strings | 6 |
|---|---|
| String spacing | 11.3 mm adjacent-string pitch; 56.5 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Six pivot screws: 56 mm outer screw centres, 11.2 mm screw pitch (manufacturer drawing) |
| Saddle type | Steel (Sheet Metal) |
| Materials | Sheet-steel saddles; steel block |
| Tremolo arm / thread | B1/B2 arm; B1 shaft diameter 4.8 mm; manufacturer specifies U.S. threads but does not give pitch on reviewed page |
| Radius | Not documented in reviewed manufacturer sources |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
GotohGE103B
| Strings | 6 |
|---|---|
| String spacing | 10.4 mm adjacent-string pitch; 52 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Two posts, 74 mm centre-to-centre (manufacturer drawing); M4 posts |
| Saddle type | Hard Zinc |
| Materials | Hard Zinc saddles; base alloy not stated on reviewed page |
| Tremolo arm / thread | Not applicable (fixed bridge) |
| Radius | 300 mm |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
GotohGE103B-T
| Strings | 6 |
|---|---|
| String spacing | 10.4 mm adjacent-string pitch; 52 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Two posts, 74 mm centre-to-centre (manufacturer drawing); M8 studs, 11.3 mm diameter inserts |
| Saddle type | Hard Zinc |
| Materials | Hard Zinc saddles; base alloy not stated on reviewed page |
| Tremolo arm / thread | Not applicable (fixed bridge) |
| Radius | 300 mm |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
GotohGE1996T
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent-string pitch; 54 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Two pivot posts, 74 mm centre-to-centre; M8 studs with 11.3 mm diameter inserts (manufacturer drawing) |
| Saddle type | Processed steel locking saddles |
| Materials | Steel saddles; baseplate and block alloy not stated on reviewed product page |
| Tremolo arm / thread | F3 arm, 5.5 mm shaft diameter; thread pitch not specified in reviewed sources |
| Radius | 350 mm |
| Fitment / other specifications | Block height options: 33mm, 36mm, 40mm; Stud-lock system; available left-handed |
Specification sources
Drawings & installation documents
GotohGE1996T-7
| Strings | 7 |
|---|---|
| String spacing | 10.8 mm adjacent-string pitch; 64.8 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Two pivot posts, 84.8 mm centre-to-centre; M8 studs with 11.3 mm diameter inserts (manufacturer drawing) |
| Saddle type | Processed steel locking saddles |
| Materials | Steel saddles; baseplate and block alloy not stated on reviewed product page |
| Tremolo arm / thread | F3 arm, 5.5 mm shaft diameter; thread pitch not specified in reviewed sources |
| Radius | 430 mm |
| Fitment / other specifications | Block height options: 33mm, 36mm, 40mm; Stud-lock system; available left-handed |
Specification sources
Drawings & installation documents
GotohGTC101
| Strings | 6 |
|---|---|
| String spacing | 10.5 mm adjacent-string pitch; 52.5 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Three mounting screws, 67 mm outer screw span (2 × 33.5 mm) in manufacturer drawing |
| Saddle type | Brass |
| Materials | Brass saddles; base alloy not stated on reviewed page |
| Tremolo arm / thread | Not applicable (fixed bridge) |
| Radius | Not documented in reviewed manufacturer sources |
| Fitment / other specifications | Baseplate 75 × 42 mm in manufacturer drawing |
Specification sources
Drawings & installation documents
GotohGTC102
| Strings | 6 |
|---|---|
| String spacing | 10.5 mm adjacent-string pitch; 52.5 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Three mounting screws, 67 mm outer screw span (2 × 33.5 mm) in manufacturer drawing |
| Saddle type | Steel |
| Materials | Steel saddles; base alloy not stated on reviewed page |
| Tremolo arm / thread | Not applicable (fixed bridge) |
| Radius | Not documented in reviewed manufacturer sources |
| Fitment / other specifications | Baseplate 75 × 42 mm in manufacturer drawing |
Specification sources
Drawings & installation documents
GotohGTC201
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent-string pitch; 54 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Four rear mounting screws, 64.8 mm outer span (3 × 21.6 mm) in manufacturer drawing |
| Saddle type | Brass |
| Materials | Brass saddles; base alloy not stated on reviewed page |
| Tremolo arm / thread | Not applicable (fixed bridge) |
| Radius | Not documented in reviewed manufacturer sources |
| Fitment / other specifications | Baseplate 79.8 × 101.5 mm in manufacturer drawing |
Specification sources
Drawings & installation documents
GotohGTC202
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent-string pitch; 54 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Four rear mounting screws, 64.8 mm outer span (3 × 21.6 mm) in manufacturer drawing |
| Saddle type | Steel |
| Materials | Steel saddles; base alloy not stated on reviewed page |
| Tremolo arm / thread | Not applicable (fixed bridge) |
| Radius | Not documented in reviewed manufacturer sources |
| Fitment / other specifications | Baseplate 79.8 × 101.5 mm in manufacturer drawing |
Specification sources
Drawings & installation documents
GotohNS510T-FE1
| Strings | 6 |
|---|---|
| String spacing | 10.5 mm adjacent-string pitch; 52.5 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Two pivot posts, 56 mm centre-to-centre; M6 studs with 10 mm diameter inserts (manufacturer drawing) |
| Saddle type | Steel |
| Materials | Chromium-molybdenum steel baseplate (510 series); steel saddles; block alloy not specified on model page |
| Tremolo arm / thread | A7 arm, 5.5 mm shaft diameter; thread pitch not specified in reviewed sources (shaft diameter is not a thread size) |
| Radius | Not documented in reviewed manufacturer sources |
| Fitment / other specifications | Block height options: 37mm or 42mm; Narrow spacing; product page explicitly says no FST mechanism |
Specification sources
Drawings & installation documents
GotohNS510TS-FE1
| Strings | 6 |
|---|---|
| String spacing | 10.5 mm adjacent-string pitch; 52.5 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Two pivot posts, 56 mm centre-to-centre; M6 studs with 10 mm diameter inserts (manufacturer drawing) |
| Saddle type | Steel |
| Materials | Chromium-molybdenum steel baseplate (510 series); steel saddles; steel block |
| Tremolo arm / thread | A7 arm, 5.5 mm shaft diameter; thread pitch not specified in reviewed sources (shaft diameter is not a thread size) |
| Radius | Not documented in reviewed manufacturer sources |
| Fitment / other specifications | Block height options: 37mm or 42mm; Narrow spacing; product page explicitly says no FST mechanism |
Specification sources
Drawings & installation documents
Graph Tech
Graph TechResoMax NV1 — 4 mm posts
| Strings | 6 |
|---|---|
| String spacing | 52.4 mm / 2-1/16 in E–E string spread (official measurement guide) |
| Mounting / screw / post spacing | 74 mm post spacing; 4 mm bridge support pin diameter; M5×0.8 post mounting thread. Support pin diameter differs from threaded mounting section. |
| Saddle type | ResoMax alloy saddles |
| Materials | ResoMax alloy bridge; plated finish; magnetic AutoLock retention |
| Tremolo arm / thread | Not applicable — fixed bridge |
| Radius | 12 in / 305 mm |
| Fitment / other specifications | Check the official Tune-o-matic measurement guide against the original bridge. Some 1990s Samick Epiphone bridges have nonstandard spacing. |
Specification sources
Drawings & installation documents
Graph TechResoMax NV2 — 4 mm posts
| Strings | 6 |
|---|---|
| String spacing | 52.4 mm / 2-1/16 in E–E string spread (official measurement guide) |
| Mounting / screw / post spacing | 74 mm post spacing; 4 mm bridge support pin diameter; M5×0.8 post mounting thread. Support pin diameter differs from threaded mounting section. |
| Saddle type | String Saver saddles |
| Materials | ResoMax alloy bridge; plated finish; magnetic AutoLock retention |
| Tremolo arm / thread | Not applicable — fixed bridge |
| Radius | 12 in / 305 mm |
| Fitment / other specifications | Check the official Tune-o-matic measurement guide against the original bridge. Some 1990s Samick Epiphone bridges have nonstandard spacing. |
Specification sources
Drawings & installation documents
Graph TechResoMax NV2 — 6 mm posts
| Strings | 6 |
|---|---|
| String spacing | 52.4 mm / 2-1/16 in E–E string spread (official measurement guide) |
| Mounting / screw / post spacing | 74 mm post spacing; 6 mm bridge support pin diameter; M8×1.25 post mounting thread. Support pin diameter differs from threaded mounting section. |
| Saddle type | String Saver saddles |
| Materials | ResoMax alloy bridge; plated finish; magnetic AutoLock retention |
| Tremolo arm / thread | Not applicable — fixed bridge |
| Radius | 12 in / 305 mm |
| Fitment / other specifications | Check the official Tune-o-matic measurement guide against the original bridge. Some 1990s Samick Epiphone bridges have nonstandard spacing. |
Specification sources
Drawings & installation documents
Guitar Fetish
Guitar FetishD16 Two-Point Hardened Steel
| Strings | 6 |
|---|---|
| String spacing | Not documented in the cited manufacturer source. |
| Mounting / screw / post spacing | 2 7/32-inch stud centres. |
| Saddle type | Stainless steel. |
| Materials | Hardened steel baseplate; full-size steel block and hardened steel arm. |
| Tremolo arm / thread | Push-in arm with tension-adjustable sleeve; no screw-in arm thread. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Guitar FetishD44 USA Solid Steel Tremolo
| Strings | 6 |
|---|---|
| String spacing | 2 7/32 inches E–E; maker gives approximately 11.3 mm per string. |
| Mounting / screw / post spacing | Six-screw; maker specifies 56.5 mm between outer screws. |
| Saddle type | Saddle alloy not stated in cited description. |
| Materials | Case-hardened steel baseplate; full-size lead-free steel block; hardened steel arm. |
| Tremolo arm / thread | Screw-in arm; thread diameter/pitch not documented. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Guitar FetishD67 USA Solid Brass Block Tremolo
| Strings | 6 |
|---|---|
| String spacing | 2 7/32 inches E–E; approximately 11.3 mm per string. |
| Mounting / screw / post spacing | Six-screw; 2 7/32 inches between outside screw centres. |
| Saddle type | Saddle alloy not stated in cited description. |
| Materials | Case-hardened steel baseplate; full-size brass block; hardened steel arm. |
| Tremolo arm / thread | Screw-in arm; thread diameter/pitch not documented. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Guitar FetishD92 Shorty Steel Block Import Tremolo
| Strings | 6 |
|---|---|
| String spacing | 10.5 mm per string in title; 2 1/16-inch E–E in description. |
| Mounting / screw / post spacing | Six-screw; 52.5 mm outside mounting centres. |
| Saddle type | Bent steel with stainless adjustment screws. |
| Materials | Hardened steel baseplate and arm; steel sustain block. |
| Tremolo arm / thread | Screw-in arm; thread diameter/pitch not documented. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Marketed for thinner import bodies; exact block length not supplied on cited page. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Guitar FetishVintage Import Tremolo (Mexican/Korean/Chinese fit)
| Strings | 6 |
|---|---|
| String spacing | 10.5 mm per string. |
| Mounting / screw / post spacing | Six case-hardened screws; described as import pattern, numeric screw centres not stated. |
| Saddle type | Vintage bent-steel. |
| Materials | Steel saddles; tapered block alloy not stated. |
| Tremolo arm / thread | Screw-in arm; thread diameter/pitch not documented. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Fit is model-dependent; check physical mounting pattern rather than country of manufacture alone. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Guyker
GuykerGG1009A
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent-string pitch; 54 mm E–e span calculated for uniform spacing |
| Mounting / screw / post spacing | Six-point layout; mounting screw span not specified in reviewed table |
| Saddle type | Brass saddles |
| Materials | Brass saddles and block; baseplate alloy not specified |
| Tremolo arm / thread | Push-in arm, 5.5 mm shaft diameter; not a screw-in thread size |
| Radius | Not documented in reviewed manufacturer source |
| Fitment / other specifications | Plate 85 × 41 mm; block 63.2 × 13 × 39.4 mm; overall height 51.4 mm. Do not use the product table’s ambiguous saddle width/height labels as fitment dimensions; use drawing. |
Specification sources
Drawings & installation documents
GuykerGG1009A-S
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent-string pitch; 54 mm E–e span calculated for uniform spacing |
| Mounting / screw / post spacing | Source conflict: page describes a six-point layout but lists two mounting studs; confirm actual mount with maker before ordering |
| Saddle type | Stainless steel locking saddles |
| Materials | Stainless steel locking saddles; brass block; base alloy not specified |
| Tremolo arm / thread | Push-in arm, 5.5 mm shaft diameter; not an arm thread size |
| Radius | Not documented in reviewed manufacturer source |
| Fitment / other specifications | Plate 85 × 41 mm; block 63.2 × 13 × 39.4 mm; overall height 51.4 mm. Manufacturer labels dimensions approximate. Mounting details require confirmation. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
GuykerGG1013A
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent-string pitch; 54 mm E–e span calculated for uniform spacing |
| Mounting / screw / post spacing | Six-point mounting; screw span not specified in reviewed manufacturer text |
| Saddle type | Roller saddles; alloy not specified |
| Materials | Brass block; other component alloys not specified |
| Tremolo arm / thread | 5.5 mm arm diameter; shaft measurement is not a thread specification |
| Radius | Not documented in reviewed manufacturer source |
| Fitment / other specifications | Bridge body 83.1 × 40.3 mm; overall height 49.5 mm. Direct manufacturer-linked dimension image could not be fetched; consult product page. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
GuykerGG2001
| Strings | 6 |
|---|---|
| String spacing | 10.5 mm adjacent-string pitch; 52.5 mm E–e span calculated for uniform spacing |
| Mounting / screw / post spacing | Two posts, 56.4 mm centre-to-centre |
| Saddle type | Brass saddles |
| Materials | Steel baseplate, brass saddles and block |
| Tremolo arm / thread | Push-in arm; no screw-in arm thread specified |
| Radius | Not documented in reviewed manufacturer source |
| Fitment / other specifications | Overall width 83 mm. Manufacturer URL retains older bent-steel wording, but the current title and specification table state brass saddles. |
Specification sources
Drawings & installation documents
GuykerGG901X
| Strings | 6 |
|---|---|
| String spacing | 10.3–10.8 mm adjustable adjacent-string spacing |
| Mounting / screw / post spacing | Removable two-point front plate; posts 56 mm centre-to-centre |
| Saddle type | Zinc-alloy saddles; individually height/intonation adjustable |
| Materials | Stainless steel baseplate and arm; zinc-alloy saddles and block |
| Tremolo arm / thread | Stainless steel arm; thread dimensions not specified |
| Radius | Individual saddle height adjustment |
| Fitment / other specifications | Plate 83 × 40.55 mm; block cross-section 63 × 13 mm; overall depth 42.4 mm; front plate length 73.5 mm. |
Specification sources
Drawings & installation documents
GuykerGG902
| Strings | 6 |
|---|---|
| String spacing | 10.3–10.8 mm adjustable adjacent-string spacing |
| Mounting / screw / post spacing | Two posts, 56 mm centre-to-centre |
| Saddle type | CNC brass saddles; individually height/intonation adjustable |
| Materials | Hot-formed steel baseplate, brass block, brass saddles |
| Tremolo arm / thread | Stainless steel arm; thread dimensions not specified |
| Radius | Individual saddle height adjustment |
| Fitment / other specifications | Plate 83 × 40 mm; block cross-section 63 × 13 mm; overall depth 42.4 mm. Manufacturer describes 10.5 and 10.8 mm saddle configurations. |
Specification sources
Drawings & installation documents
Göldo
Göldo3-Point-Vario HWG2
| Strings | 6 |
|---|---|
| String spacing | 52 mm E–E |
| Mounting / screw / post spacing | 72.3–74.0 mm stud centres; 4 mm stud diameter. |
| Saddle type | Stainless steel; three contact points; slotted intonation screws face tailpiece. |
| Materials | Stainless saddles; body alloy not specified. |
| Tremolo arm / thread | Not applicable. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
GöldoCompensated Wraparound HWG3
| Strings | 6 |
|---|---|
| String spacing | Not documented in the cited manufacturer source. |
| Mounting / screw / post spacing | 81.5 mm bolt centres; supplied M8 and 5/16-inch US studs (pitch unspecified). |
| Saddle type | Compensated support; two M3 grub screws adjust overall intonation. |
| Materials | One-piece aluminum. |
| Tremolo arm / thread | Not applicable. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Only specified for string sets with plain G. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
GöldoG5 TGD5
| Strings | 6 |
|---|---|
| String spacing | 45 mm at string axle; this is not the bridge E–E spacing. |
| Mounting / screw / post spacing | Four 3.5 × 32 mm wood screws supplied; hole-centre pattern not stated. |
| Saddle type | Separate bridge required. |
| Materials | Aluminum frame; bearing-supported axle and tension roller. |
| Tremolo arm / thread | Insert round arm held by two grub screws; adjustable length/height. Holder has 5 mm threaded locking stem, not an arm screw-in thread. |
| Radius | Set by separate bridge. |
| Fitment / other specifications | 102 mm long; 100 mm overall width; 84 mm front width; 55 mm roller width. |
Specification sources
Drawings & installation documents
GöldoHWW1 Aluminum Wrap-Around
| Strings | 6 |
|---|---|
| String spacing | 52 mm E–E |
| Mounting / screw / post spacing | 81.5 mm stud centres; bushings and studs included. |
| Saddle type | One-piece compensated ridge; B/G support adjustable. |
| Materials | Cast aluminum. |
| Tremolo arm / thread | Not applicable. |
| Radius | 14 inches |
| Fitment / other specifications | Overall 100.7 × 13 × 23.5 mm (width × height × depth). |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
GöldoTurnómatic G-Type HW05
| Strings | 6 |
|---|---|
| String spacing | 52 mm E–E |
| Mounting / screw / post spacing | 73.5 mm bolt centres; M4 bolts; 7.5 mm bushing diameter. |
| Saddle type | Brass rollers. |
| Materials | Brass rollers; bridge-body alloy not specified. |
| Tremolo arm / thread | Not applicable. |
| Radius | 14 inches |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Hipshot
HipshotFixed 6-string — 0.125 in floor
| Strings | 6 |
|---|---|
| String spacing | 0.416 in per string; 2.080 in / 52.8 mm E–E (manufacturer FAQ) |
| Mounting / screw / post spacing | Three staggered mounting holes; string-through body. See drawing for the complete pattern. |
| Saddle type | Individual stainless steel saddles |
| Materials | Machined solid brass plate with side walls; stainless steel saddles |
| Tremolo arm / thread | Not applicable — fixed bridge |
| Radius | Not published in the cited source |
| Fitment / other specifications | Floor height 0.125 in; string height 0.30–0.47 in in official drawing. Ambidextrous. Height option must match neck angle / neck pocket. |
Specification sources
Drawings & installation documents
HipshotFixed 6-string — 0.175 in floor
| Strings | 6 |
|---|---|
| String spacing | 0.416 in per string; 2.080 in / 52.8 mm E–E (manufacturer FAQ) |
| Mounting / screw / post spacing | Three staggered mounting holes; string-through body. See drawing for the complete pattern. |
| Saddle type | Individual stainless steel saddles |
| Materials | Machined solid brass plate with side walls; stainless steel saddles |
| Tremolo arm / thread | Not applicable — fixed bridge |
| Radius | Not published in the cited source |
| Fitment / other specifications | Floor height 0.175 in; string height 0.35–0.52 in in official drawing. Ambidextrous. Height option must match neck angle / neck pocket. |
Specification sources
Drawings & installation documents
HipshotUS Contour 6-string
| Strings | 6 |
|---|---|
| String spacing | 0.416 in per string; 2.080 in / 52.8 mm E–E (manufacturer FAQ) |
| Mounting / screw / post spacing | Two-post; American Standard routing convention. See drawing for insert holes and adapter dimensions. |
| Saddle type | Stainless steel; individual height and intonation adjustment |
| Materials | Machined brass top plate; hardened steel pivot pins; machined steel block |
| Tremolo arm / thread | Press-in arm with adjustable tension; no screw-in arm thread |
| Radius | Not published in the cited source |
| Fitment / other specifications | Block options: 42 mm standard or 38 mm short. Drawing specifies 0.300 in minimum string height. The drawing labels 10-32 and 1/4-28 for mounting hardware, not the arm. |
Specification sources
Drawings & installation documents
HipshotUS Contour 7-string
| Strings | 7 |
|---|---|
| String spacing | 0.416 in per adjacent string (manufacturer drawing) |
| Mounting / screw / post spacing | Two-post; model-specific routing template required |
| Saddle type | Stainless steel; gold version uses gold-plated brass saddles |
| Materials | Machined brass top plate; hardened steel pivot pins; machined steel block |
| Tremolo arm / thread | Adjustable-tension press-in arm |
| Radius | Not published in the cited source |
| Fitment / other specifications | 42 mm standard / 38 mm short block listed. Drawing gives 0.300 in minimum string height and 18.8 oz with mounting hardware. |
Specification sources
Drawings & installation documents
Ibanez
IbanezEdge
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent-string pitch on the cited six-string guitar; E–E span not separately specified. |
| Mounting / screw / post spacing | Knife-edge pivot on locking studs; post centre spacing not specified. |
| Saddle type | String-clamping saddles with fine tuners; individual height is not adjustable. |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | Snap-in arm; removable plastic washers control rotational resistance. No screw-in arm thread. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Manual tools: 1.5 mm stud-lock key, 4 mm height key, 2 mm saddle-lock key. Cut off string ball ends before clamping. |
Specification sources
Drawings & installation documents
IbanezEdge III
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Knife-edge stud pivot; post centre spacing not specified. |
| Saddle type | String-clamping saddles with fine tuners. |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | Standard version snaps in; 2 mm torque adjustment and 3 mm arm-height adjustment. Herman Li EGEN8 variant uses a screw-in arm; thread size unspecified. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Arm attachment differs on the Herman Li version; identify the variant before buying replacement arms. |
Specification sources
Drawings & installation documents
IbanezEdge-Zero
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Locking studs; 2 mm stud-lock key and 3 mm bridge-height key. Post spacing not specified. |
| Saddle type | String-clamping saddles, fine tuners and stored intonation-adjustment bolts. |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | Snap-in arm with torque adjustment cap. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Zero-point spring system can be disabled for conventional floating use. |
Specification sources
Drawings & installation documents
IbanezEdge-Zero II
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent-string pitch on JS140M; E–E span not separately specified. |
| Mounting / screw / post spacing | Knife edges and locking studs; 2 mm stud-lock key, 3 mm height key. Post spacing not specified. |
| Saddle type | String-clamping saddles and fine tuners. |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | Snap-in arm secured by an adjustable torque cap; arm thread pitch not specified. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Versions exist with and without the zero-point system. Confirm the exact fitted assembly before ordering parts. |
Specification sources
Drawings & installation documents
IbanezGibraltar Standard II
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Not documented in cited sources |
| Saddle type | Independent saddles; 1.5 mm height key and 2.5 mm intonation key. |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | Not applicable — fixed bridge. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | String-through-body loading; verify six-, seven- or extended-range version separately. |
Specification sources
Drawings & installation documents
IbanezGibraltar Standard III
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent-string pitch on six-string RG652AHMFX; E–E span not separately specified. |
| Mounting / screw / post spacing | Not documented in cited sources |
| Saddle type | Individual saddles on a redesigned baseplate. |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | Not applicable — fixed bridge. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Gibraltar Standard III is listed separately from Standard II; do not assume identical drilling. |
Specification sources
Drawings & installation documents
IbanezGotoh T1502 (AZ OEM)
| Strings | 6 |
|---|---|
| String spacing | 10.5 mm adjacent-string pitch on AZ47P1QM; E–E span not separately specified. |
| Mounting / screw / post spacing | Locking studs: 1.5 mm stud-lock key and 2.5 mm bridge-height key. Post centre spacing not specified. |
| Saddle type | Steel saddles with individual height adjustment. |
| Materials | Steel saddles; die-cast zinc tremolo block. |
| Tremolo arm / thread | Snap-in arm with torque adjustment cap. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Gotoh-built Ibanez OEM model; block material differs from T1802. |
Specification sources
Drawings & installation documents
IbanezGotoh T1802 (AZ OEM)
| Strings | 6 |
|---|---|
| String spacing | 10.5 mm adjacent-string pitch on AZ2402; E–E span not separately specified. |
| Mounting / screw / post spacing | Locking studs: 1.5 mm stud-lock key and 2.5 mm bridge-height key. Post centre spacing not specified. |
| Saddle type | Machined titanium saddles; individual height adjustment with 1.5 mm hex key. |
| Materials | Titanium saddles; machined steel tremolo block. |
| Tremolo arm / thread | Snap-in arm with torque adjustment cap. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Gotoh-built Ibanez OEM model. Do not substitute dimensions from another Gotoh bridge. |
Specification sources
Drawings & installation documents
IbanezLo-Pro Edge
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent-string pitch on the cited six-string guitar; E–E span not separately specified. |
| Mounting / screw / post spacing | Knife-edge pivot on locking studs; post centre spacing not specified. |
| Saddle type | String-clamping saddles with fine tuners; individual height is not adjustable. |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | Snap-in arm; removable plastic washers control rotational resistance. No screw-in arm thread. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Manual tools: 1.5 mm stud-lock key, 4 mm height key, 2 mm saddle-lock key. Cut off string ball ends before clamping. |
Specification sources
Drawings & installation documents
IbanezSynchroniZR
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Height adjusted at studs with 3 mm hex key; centre spacing not specified. |
| Saddle type | Intonation-adjustable saddles; individual string height is not adjustable. |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | Snap-in arm with torque adjustment cap. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Rear arm-up stopper permits dive-only operation. Strings load through the tremolo block from the rear. |
Specification sources
Drawings & installation documents
IbanezZR-2
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Stud-mounted bridge; height adjusted with 3 mm hex key. Post spacing not specified. |
| Saddle type | String-clamping saddles, fine tuners and stored intonation-adjustment bolts. |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | Snap-in arm with torque adjustment cap. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Manual covers both ZR-2 and Edge-Zero. Do not assume their mounting or pivot parts interchange. |
Specification sources
Drawings & installation documents
Kahler
Kahler2200 Professional Stud Mount
| Strings | 6 / 7 / 8 / 9 / 10 |
|---|---|
| String spacing | Adjustable side to side; see model/string-count table in linked specification. |
| Mounting / screw / post spacing | Stud mount with riser wheels; exact center spacing requires selected stud-set drawing. |
| Saddle type | Steel, brass or Teflon Glass roller options. |
| Materials | Steel, aluminum or brass cam options; configuration-dependent. |
| Tremolo arm / thread | Right/left-handed versions with arm-tension clutches; thread not established. |
| Radius | Saddle heights and stud risers adjust action/radius. |
| Fitment / other specifications | Top route only; can lock to fixed-bridge mode. Select exact string count and stud threading before fitment. |
Specification sources
Drawings & installation documents
Kahler2300 Professional Flat Mount
| Strings | 6 |
|---|---|
| String spacing | Adjustable: six-string outside spread 1.900–2.125+ inches in series chart. |
| Mounting / screw / post spacing | Flat mount; four screws (see installation drawing). |
| Saddle type | 303 stainless-steel saddles. |
| Materials | 1018CRS steel cam. |
| Tremolo arm / thread | Thread size not established. |
| Radius | Adjustable saddle heights. |
| Fitment / other specifications | Top-routed cam/ball-bearing system. |
Specification sources
Drawings & installation documents
Kahler2310 Professional Flat Mount
| Strings | 6 |
|---|---|
| String spacing | Adjustable: six-string outside spread 1.900–2.125+ inches in series chart. |
| Mounting / screw / post spacing | Flat mount; four screws (see installation drawing). |
| Saddle type | 360HH brass saddles. |
| Materials | 5060T6–7075 aircraft-grade aluminum cam (as specified). |
| Tremolo arm / thread | Thread size not established. |
| Radius | Adjustable saddle heights. |
| Fitment / other specifications | Top-routed cam/ball-bearing system. |
Specification sources
Drawings & installation documents
Kahler2315 Professional Flat Mount
| Strings | 6 |
|---|---|
| String spacing | Adjustable: six-string outside spread 1.900–2.125+ inches in series chart. |
| Mounting / screw / post spacing | Flat mount; four screws (see installation drawing). |
| Saddle type | 303 steel saddles. |
| Materials | 360HH brass cam. |
| Tremolo arm / thread | Thread size not established. |
| Radius | Adjustable saddle heights. |
| Fitment / other specifications | Top-routed cam/ball-bearing system. |
Specification sources
Drawings & installation documents
Kahler2320 Professional Flat Mount
| Strings | 6 |
|---|---|
| String spacing | Adjustable: six-string outside spread 1.900–2.125+ inches in series chart. |
| Mounting / screw / post spacing | Flat mount; four screws (see installation drawing). |
| Saddle type | 360HH brass saddles. |
| Materials | 360HH brass cam. |
| Tremolo arm / thread | Thread size not established. |
| Radius | Adjustable saddle heights. |
| Fitment / other specifications | Top-routed cam/ball-bearing system. |
Specification sources
Drawings & installation documents
Kahler2700 Spyder
| Strings | 6 |
|---|---|
| String spacing | Not documented in the sources reviewed. |
| Mounting / screw / post spacing | Spyder-specific studs. |
| Saddle type | Double-locking Spyder saddles. |
| Materials | Block choices include Standard, Auto Latch, Blunt Fatty Big Brass and Godiva Big Brass. |
| Tremolo arm / thread | Thread size not documented in reviewed source. |
| Radius | Not documented in the sources reviewed. |
| Fitment / other specifications | Limited new-old-stock run; manufacturer says installation requires modifications unless the guitar was built for Spyder. Brass block length: 32/37/42 mm via stacker plates. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Kahler2700 Steeler Professional
| Strings | 6 |
|---|---|
| String spacing | Not documented in the sources reviewed. |
| Mounting / screw / post spacing | Steeler studs: SAE with inserts or M8 × 1.25 without inserts. |
| Saddle type | Double-locking professional saddles. |
| Materials | Block choices include Standard, Auto Latch, Blunt Fatty Big Brass and Godiva Big Brass. |
| Tremolo arm / thread | Thread size not documented in reviewed source. |
| Radius | Not documented in the sources reviewed. |
| Fitment / other specifications | Accepts ball-end strings while remaining double-locking. Brass block length: 32/37/42 mm via stacker plates. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Kahler2700 Steeler Traditional
| Strings | 6 |
|---|---|
| String spacing | Not documented in the sources reviewed. |
| Mounting / screw / post spacing | Steeler studs: SAE with inserts or M8 × 1.25 without inserts. |
| Saddle type | Double-locking traditional saddles. |
| Materials | Block choices include Standard, Auto Latch, Blunt Fatty Big Brass and Godiva Big Brass. |
| Tremolo arm / thread | Thread size not documented in reviewed source. |
| Radius | Not documented in the sources reviewed. |
| Fitment / other specifications | Traditional saddle uses a captive thumb block to center the string. Brass block length: 32/37/42 mm via stacker plates. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Kahler7300 Hybrid Flat Mount
| Strings | 6 |
|---|---|
| String spacing | Side-to-side adjustable; exact range not separately confirmed for Hybrid. |
| Mounting / screw / post spacing | Flat mount; top route only. |
| Saddle type | Brass saddle rollers. |
| Materials | Brass cam; baseplate alloy not documented in reviewed listing. |
| Tremolo arm / thread | Arm with tension clutch; exact thread not documented. |
| Radius | Individual saddle height / radius adjustment. |
| Fitment / other specifications | Locks into fixed-bridge mode; cam/ball-bearing drive. |
Specification sources
Drawings & installation documents
Kluson
KlusonK2PT Two-Post Steel Block
| Strings | 6 |
|---|---|
| String spacing | 2 1/16 inches E–E (maker lists 52.5 mm). |
| Mounting / screw / post spacing | 2 7/32-inch stud centres (maker lists 56.5 mm); 10 mm OD brass inserts. Stud-thread specification is contradictory on source page. |
| Saddle type | Kluson embossed stamped steel. |
| Materials | Steel block and studs; brass inserts. |
| Tremolo arm / thread | Traditional screw-in arm; arm thread not given. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Official page lists both 1/4-28 and 1/2×28 for stud thread. Treat thread as unconfirmed until clarified; optional brass block sold separately. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
KlusonKABRNW Non-Wire ABR-1
| Strings | 6 |
|---|---|
| String spacing | 10.4 mm saddle spacing; E–E not expressly stated. |
| Mounting / screw / post spacing | 2.93-inch bridge centres; 4 mm smooth post top. Threaded rods and thumbwheels, without body inserts. |
| Saddle type | Brass; non-wire retention through string pressure and screw-end fit. |
| Materials | Not documented in the cited manufacturer source. |
| Tremolo arm / thread | Not applicable. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
KlusonKASHY American Standard Tele Hybrid
| Strings | 6 |
|---|---|
| String spacing | Not documented in the cited manufacturer source. |
| Mounting / screw / post spacing | Uses original three rear mounting screw holes and American Standard string-through/pickup positions. Dimensions not stated. |
| Saddle type | Three reduced-height intonated brass saddles. |
| Materials | Stamped steel baseplate; brass saddles. |
| Tremolo arm / thread | Not applicable. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Converts an American Standard six-saddle Tele bridge to three saddles; do not assume vintage four-hole pattern. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
KlusonKHB Harmonica
| Strings | 6 |
|---|---|
| String spacing | 10.4 mm per string; 52 mm E–E. |
| Mounting / screw / post spacing | 73 mm (2 7/8-inch) post centres; M8 × 1.25 studs; 4.7 mm top diameter; 9.5 mm stud-base diameter. |
| Saddle type | Brass; plated or unplated options. |
| Materials | Milled bell-brass or billet-steel body. |
| Tremolo arm / thread | Not applicable. |
| Radius | 12 inches |
| Fitment / other specifications | Body 3.5 × 1 inches; centre height 25/64 inch. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
KlusonKNTOM Standard Nashville
| Strings | 6 |
|---|---|
| String spacing | 10.4 mm saddle spacing; E–E not expressly stated. |
| Mounting / screw / post spacing | 2.93 inches / 74.5 mm post centres; M5 × 0.8 mounting thread; post top 4.95 mm diameter. |
| Saddle type | Centre-notched Zmac alloy. |
| Materials | Zmac body and saddles; brass post/thumbwheel. |
| Tremolo arm / thread | Not applicable. |
| Radius | 12 inches |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
KlusonKNTS Vintage Narrow Steel Block
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm per string; 54 mm E–E. |
| Mounting / screw / post spacing | Six-screw; 2 7/32-inch outer screw centres (maker rounds to 56.5 mm). |
| Saddle type | Stamped steel, Kluson embossed. |
| Materials | Machined steel block; stamped steel saddles. |
| Tremolo arm / thread | Arm and tip supplied; thread not stated. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
KlusonKSB American Standard Hardtail
| Strings | 6 |
|---|---|
| String spacing | 2 1/16 inches E–E. |
| Mounting / screw / post spacing | American Standard Strat pattern; replacement for Fender 003-2909-000. Exact screw centres not stated. |
| Saddle type | Plated stainless steel, offset adjustment screws. |
| Materials | Stainless saddles; thicker baseplate, alloy not specified. |
| Tremolo arm / thread | Not applicable. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | String-through-body only. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Mastery
MasteryM1
| Strings | 6 |
|---|---|
| String spacing | 52 mm E–E |
| Mounting / screw / post spacing | 2 7/8-inch post centres; posts for .310-inch ID USA-spec thimbles. |
| Saddle type | Two adjustable brass saddles, hard-chrome plated. |
| Materials | 304 stainless baseplate; stainless hardware. |
| Tremolo arm / thread | Not applicable; use separate vibrato. |
| Radius | Adjustable for common radii from 7.25 inches upward. |
| Fitment / other specifications | Check the current maker fit guide; some newer offsets require replacement thimbles. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
MasteryM2
| Strings | 6 |
|---|---|
| String spacing | 52 mm E–E |
| Mounting / screw / post spacing | 2 7/8-inch post centres; additional posts for .323-inch ID MIJ-spec thimbles. |
| Saddle type | Two adjustable brass saddles, hard-chrome plated. |
| Materials | 304 stainless baseplate; stainless hardware. |
| Tremolo arm / thread | Not applicable; use separate vibrato. |
| Radius | Adjustable for common radii from 7.25 inches upward. |
| Fitment / other specifications | Check the current maker fit guide; some newer offsets require replacement thimbles. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
MasteryM3
| Strings | 6 |
|---|---|
| String spacing | 52 mm E–E (Mastery saddle design). |
| Mounting / screw / post spacing | Four-hole vintage Tele footprint; supplied #6 screws. |
| Saddle type | Electropolished brass saddles and swivels. |
| Materials | Stainless mounting screws; see maker footprint drawing for exact installation geometry. |
| Tremolo arm / thread | Not applicable. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
MasteryM4
| Strings | 6 |
|---|---|
| String spacing | 52 mm E–E (Mastery saddle design). |
| Mounting / screw / post spacing | Four-hole vintage Tele footprint; supplied #6 screws. |
| Saddle type | Hard-chrome-plated brass saddles. |
| Materials | Stainless mounting screws; see maker footprint drawing for exact installation geometry. |
| Tremolo arm / thread | Not applicable. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
MasteryM5
| Strings | 6 |
|---|---|
| String spacing | 48 mm E–E |
| Mounting / screw / post spacing | Four stainless posts attach to body plate using cone-point screws; two body-plate mounting screws supplied. |
| Saddle type | Hard-chrome-plated brass saddles. |
| Materials | Stainless hardware. |
| Tremolo arm / thread | Not applicable. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
MasteryM6
| Strings | 6 |
|---|---|
| String spacing | 52 mm E–E (Mastery saddle design). |
| Mounting / screw / post spacing | Four-wood-screw vintage Tele hardtail footprint; supplied #6 screws. |
| Saddle type | Electropolished brass saddles and swivels. |
| Materials | Stainless mounting screws; see maker footprint drawing for exact installation geometry. |
| Tremolo arm / thread | Not applicable. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
MasteryM8
| Strings | 6 |
|---|---|
| String spacing | 52 mm E–E (Mastery saddle design). |
| Mounting / screw / post spacing | Three-wood-screw hardtail footprint; supplied #6 screws. |
| Saddle type | Electropolished brass saddles and swivels. |
| Materials | Stainless mounting screws; see maker footprint drawing for exact installation geometry. |
| Tremolo arm / thread | Not applicable. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
MasteryOMV
| Strings | 6 |
|---|---|
| String spacing | Set by separate bridge. |
| Mounting / screw / post spacing | Standard offset six-wood-screw vibrato footprint. |
| Saddle type | Separate bridge required. |
| Materials | Stainless plates and arm housing; 303 stainless arm; high-carbon steel spring. |
| Tremolo arm / thread | Close-fit housing with adjustable spring plunger; thread diameter not specified. |
| Radius | Set by separate bridge. |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Music Man
Music ManJohn Petrucci Piezo Floating Tremolo (JPX 6)
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Pivot screws set bridge height; post centre spacing unspecified. |
| Saddle type | Fishman Powerbridge piezo saddles. |
| Materials | Hardened steel bridge, black finish. |
| Tremolo arm / thread | Not documented in cited sources |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Official setup keeps bridge plate level with the body and floating freely. This record describes JPX 6; other JP and Majesty variants may have different saddles and finishes. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Music ManModern Tremolo (StingRay Guitar 2017 version)
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Not documented in cited sources |
| Saddle type | Vintage bent steel saddles. |
| Materials | Steel saddles; remaining alloys unspecified. |
| Tremolo arm / thread | Not documented in cited sources |
| Radius | Not documented in cited sources |
| Fitment / other specifications | The archived StingRay guitar uses the Modern tremolo. Do not confuse this guitar bridge with StingRay bass bridges or infer post spacing from another Music Man model. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Music ManString-Through Hardtail (Silhouette version)
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Strings through the body; screw layout unspecified. |
| Saddle type | Solid steel saddles. |
| Materials | Chrome-plated hardened steel bridge with solid steel saddles. |
| Tremolo arm / thread | Not applicable — fixed bridge. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Silhouette specification lists this hardtail and an optional vintage tremolo separately; verify which version the instrument has. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Music ManVintage Floating Tremolo (Luke BFR version)
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Pivot-screw bridge; official vintage setup procedure uses a 4 mm hex drive for pivot height. Post spacing unspecified. |
| Saddle type | Bent steel saddles. |
| Materials | Chrome-plated hardened steel bridge; bent steel saddles. |
| Tremolo arm / thread | Not documented in cited sources |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Luke BFR specification describes floating operation; do not assume identical setup for every Music Man vintage tremolo guitar. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Musiclily
MusiclilyBV019
| Strings | 6 |
|---|---|
| String spacing | 11.2 mm adjacent-string pitch; 56 mm E–e span |
| Mounting / screw / post spacing | Six screws, 56 mm outer centres (11.2 mm pitch) |
| Saddle type | Solid brass modern block saddles |
| Materials | Stainless steel plate, solid brass saddles and block |
| Tremolo arm / thread | Stainless steel 5 mm push-in arm; no screw-in thread |
| Radius | Not documented in reviewed manufacturer source |
| Fitment / other specifications | 42 mm block depth; manufacturer requires body thickness greater than 45 mm. Drawing: plate 83 × 40 mm; block 75 × 13.1 mm cross-section. |
Specification sources
Drawings & installation documents
MusiclilyBV020
| Strings | 6 |
|---|---|
| String spacing | 10.5 mm adjacent-string pitch; 52.5 mm E–e span |
| Mounting / screw / post spacing | Six screws, 56 mm outer centres (11.2 mm pitch) |
| Saddle type | Hardened bent-steel vintage saddles |
| Materials | Stainless steel plate, hardened steel saddles, solid brass block |
| Tremolo arm / thread | Stainless steel 5 mm push-in arm; no screw-in thread |
| Radius | Not documented in reviewed manufacturer source |
| Fitment / other specifications | 42 mm block depth; manufacturer requires body thickness greater than 45 mm. Narrow strings with wide mounting pattern. Drawing: block 72 × 13.2 mm cross-section. |
Specification sources
Drawings & installation documents
MusiclilyBV021
| Strings | 6 |
|---|---|
| String spacing | 10.5 mm adjacent-string pitch; 52.5 mm E–e span |
| Mounting / screw / post spacing | Six screws, 56 mm outer centres (11.2 mm pitch) |
| Saddle type | Solid brass modern block saddles |
| Materials | Stainless steel plate, solid brass saddles and block |
| Tremolo arm / thread | Stainless steel 5 mm push-in arm; no screw-in thread |
| Radius | Not documented in reviewed manufacturer source |
| Fitment / other specifications | 42 mm block depth; manufacturer requires body thickness greater than 45 mm. Narrow strings with wide mounting pattern. Drawing: block 72 × 13.2 mm cross-section. |
Specification sources
Drawings & installation documents
MusiclilyBV022
| Strings | 6 |
|---|---|
| String spacing | 10.5 mm adjacent-string pitch; 52.5 mm E–e span |
| Mounting / screw / post spacing | Six notched mounting screws, 52.5 mm outer centres |
| Saddle type | Solid brass saddles |
| Materials | Solid brass plate, saddles and block; stainless steel mounting screws |
| Tremolo arm / thread | Stainless steel push-in arm; drawing marks 5 mm push-in hole |
| Radius | Not documented in reviewed manufacturer source |
| Fitment / other specifications | Knife-edge / notched-screw pivot design; 36 mm block depth. Drawing: plate 83 × 40.5 mm; block 74 × 13 mm cross-section. |
Specification sources
Drawings & installation documents
MusiclilyM211
| Strings | 6 |
|---|---|
| String spacing | 10.5 mm adjacent-string pitch; 52.5 mm E–e span |
| Mounting / screw / post spacing | Two posts, 74 mm centre-to-centre |
| Saddle type | Locking saddles; zinc alloy described for assembly |
| Materials | Zinc alloy (manufacturer does not separate component alloys) |
| Tremolo arm / thread | 6 mm collared threaded arm; thread pitch not specified |
| Radius | Not documented in reviewed manufacturer source |
| Fitment / other specifications | 34 mm tall block; supplied locking nut width 42 mm. Drawing labels arm bore Ø6 mm, not a complete M-thread pitch specification. |
Specification sources
Drawings & installation documents
MusiclilyM213
| Strings | 6 |
|---|---|
| String spacing | 10.5 mm adjacent-string pitch; 52.5 mm E–e span |
| Mounting / screw / post spacing | Six screws, 52.5 mm outer screw centres |
| Saddle type | Individual block-style saddles shown in drawing; specific alloy not separated |
| Materials | Zinc alloy (manufacturer does not separate component alloys) |
| Tremolo arm / thread | Drawing labels a 5.8 mm thread-in hole; thread pitch not specified |
| Radius | Not documented in reviewed manufacturer source |
| Fitment / other specifications | Drawing: baseplate 84 × 40 mm; block 70 × 6 × 36 mm. Manufacturer’s older product-name inch conversions are approximate; use millimetres. |
Specification sources
Drawings & installation documents
PRS
PRS2-Piece Bridge (McCarty 594)
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Not documented in cited sources |
| Saddle type | Unplated brass saddles. |
| Materials | Zinc bridge; steel bridge posts; brass thumbwheels and tailpiece posts; aluminum tailpiece. |
| Tremolo arm / thread | Not applicable — fixed bridge. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Separate bridge and tailpiece. Stud centres and threads are not specified in this guide. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
PRSAdjustable Stoptail
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Not documented in cited sources |
| Saddle type | Individually adjustable saddles; Hollowbody Piezo uses a separate piezo-equipped version. |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | Not applicable — fixed bridge. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Alternative intended for nonstandard or heavy string gauges; nickel and gold finishes described. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
PRSFiore 2-Point Steel Tremolo
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Two pivot points; post spacing unspecified. |
| Saddle type | Not documented in cited sources |
| Materials | Steel bridge, as designated by PRS. |
| Tremolo arm / thread | 4.7 mm arm/bushing diameter; not a thread pitch. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
PRSPatented Gen II Machined Tremolo
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Six knife-edge mounting screws; centre spacing unspecified. |
| Saddle type | Individually adjustable brass saddles. |
| Materials | Machined brass block, brass plate and saddles. |
| Tremolo arm / thread | Unthreaded 4.7 mm arm/bushing diameter; sleeve and tension set screw. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | PRS states the Gen II replacement is not a replacement for current Gen III bridges. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
PRSPatented Gen III Machined Tremolo
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Six knife-edge mounting screws; larger custom screw design than earlier versions. Screw spacing and thread size unspecified. |
| Saddle type | Brass, individually adjustable; compound contact geometry. |
| Materials | Machined brass block, plate and saddles. |
| Tremolo arm / thread | Unthreaded 4.7 mm arm/bushing diameter; resistance adjusted by set screw. Diameter is not thread pitch. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Gen III mounting hardware is distinct; do not assume Gen II replacement compatibility. |
Specification sources
Drawings & installation documents
PRSPatented Molded Tremolo (CE / S2 / SE)
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Six-screw PRS patented layout; screw centre spacing unspecified. |
| Saddle type | Individually adjustable brass saddles. |
| Materials | Cast steel block; brass plate and brass saddles. |
| Tremolo arm / thread | Unthreaded 4.5 mm arm/bushing diameter. Do not force the larger machined-bridge arm into this bushing. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | PRS lists compatibility with Bolt-On, S2 and SE instruments; verify the actual fitted bridge. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
PRSSE Silver Sky Tremolo
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Not documented in cited sources |
| Saddle type | Not documented in cited sources |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | 4.5 mm arm/bushing diameter; not the USA Silver Sky 4.7 mm size. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | SE Silver Sky is a separate bridge and arm fitment from the Maryland-made Silver Sky. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
PRSSilver Sky Tremolo (USA)
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Knife-edge mounting screws; screw spacing unspecified. |
| Saddle type | Saddles with thin electroless plating. |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | 4.7 mm arm/bushing diameter; not a thread specification. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Factory setup has the rear against the body and front edge clearance of 1/32 in (0.78 mm). |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
PRSWraparound Stoptail
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Not documented in cited sources |
| Saddle type | Pre-compensated string contact; end set screws provide overall intonation trim. |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | Not applicable — fixed bridge. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | PRS does not recommend a wound third string with this pre-compensated design. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Rockinger
Rockinger1602 Two-Stud Tremolo
| Strings | 6 |
|---|---|
| String spacing | 52.5 mm E–E. |
| Mounting / screw / post spacing | 58 mm stud centres. |
| Saddle type | Modern style; alloy not specified. |
| Materials | Brass block. |
| Tremolo arm / thread | Supplied arm; thread not stated. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | 40 mm block; 355 g assembly. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Rockinger1611 Standard Vintage Tremolo
| Strings | 6 |
|---|---|
| String spacing | 56 mm E–E. |
| Mounting / screw / post spacing | Six holes; 56 mm outer screw-centre spacing. |
| Saddle type | Vintage style; alloy not specified. |
| Materials | Not documented in the cited manufacturer source. |
| Tremolo arm / thread | Arm supplied; thread not stated. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | 41 mm block; 339 g assembly. Block alloy not specified. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Rockinger1616 Vintage Steel Tremolo
| Strings | 6 |
|---|---|
| String spacing | 56 mm E–E. |
| Mounting / screw / post spacing | Six holes; 56 mm between outer mounting screw centres. |
| Saddle type | Vintage-style; alloy not stated. |
| Materials | Steel block. |
| Tremolo arm / thread | Arm supplied; thread not stated. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | 41 mm block; 389 g assembly. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Rockinger2400 Non-Tremolo Bridge
| Strings | 6 |
|---|---|
| String spacing | 54 mm E–E. |
| Mounting / screw / post spacing | Three screws; 22.6 mm adjacent centres / 45.2 mm outside centres. |
| Saddle type | Vintage style. |
| Materials | Not documented in the cited manufacturer source. |
| Tremolo arm / thread | Not applicable. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | String-through-body; ferrules required. Plate 75 × 41 mm; 97 g. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Schaller
Schaller3D-6
| Strings | 6 |
|---|---|
| String spacing | Adjustable 10–11.3 mm adjacent pitch; 50–56.5 mm E–e span |
| Mounting / screw / post spacing | Three direct mounting screws, M4.2 × 25 mm; use drawing for hole layout |
| Saddle type | Adjustable brass roller saddles |
| Materials | Solid uncoated brass rollers and shafts; body alloy not specified in reviewed page |
| Tremolo arm / thread | Not applicable (fixed bridge) |
| Radius | Adjustable 7–20 inches |
| Fitment / other specifications | 3.5 mm height adjustment; optional 3 mm underlay; minimum D/G string height 11.1 mm; maximum string gauge .052 inch. Not suitable for left-handed models. |
Specification sources
Drawings & installation documents
SchallerGTM
| Strings | 6 |
|---|---|
| String spacing | 52.5 mm E–e nominal span; saddles supplied unnotched for custom string placement |
| Mounting / screw / post spacing | Two posts; accommodates 74.0–74.5 mm centre-to-centre |
| Saddle type | Unnotched individually intonated brass saddles |
| Materials | Uncoated solid brass saddles; body alloy not specified in reviewed page |
| Tremolo arm / thread | Not applicable (fixed bridge) |
| Radius | 12–14 inches depending on saddle notching |
| Fitment / other specifications | M5 stud/insert, M8 stud or M4 rod/thumbwheel mounting options. Minimum D/G string height 13.7 mm. Reverse/non-reverse versions. |
Specification sources
Drawings & installation documents
SchallerLockMeister 6
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent pitch; 54 mm E–e span |
| Mounting / screw / post spacing | Two pivot posts, 74.3 mm centre-to-centre; M7 × 0.5 studs, 10 mm diameter inserts |
| Saddle type | Hardened steel locking saddles |
| Materials | Hardened steel baseplate/saddles/nut; brass sustain block |
| Tremolo arm / thread | Arm assembly supplied; thread pitch not documented in reviewed model source (do not confuse M7 × 0.5 pivot studs or M5 fine-tuners with the arm thread) |
| Radius | 10, 12, 14 or 16 inches |
| Fitment / other specifications | 32/37/42 mm block options; 8.5 mm intonation travel; block attachment three screws at 17 mm pitch. New extended fine-tuners M5 × 10; this is not the arm thread. |
Specification sources
Drawings & installation documents
SchallerLockMeister 7
| Strings | 7 |
|---|---|
| String spacing | 10.8 mm adjacent pitch (64.8 ÷ 6); 64.8 mm outer-string span |
| Mounting / screw / post spacing | Two pivot posts, 85.1 mm centre-to-centre; M7 × 0.5 studs, 10 mm diameter inserts |
| Saddle type | Hardened steel locking saddles |
| Materials | Hardened C45 steel baseplate, steel saddles/nut; brass block |
| Tremolo arm / thread | Arm assembly supplied; thread pitch not documented in reviewed model source (do not confuse M7 × 0.5 pivot studs or M5 fine-tuners with the arm thread) |
| Radius | 20 inches |
| Fitment / other specifications | 32/37/42 mm block options; 8.5 mm intonation travel; block attachment three screws at 17 mm pitch. M5 × 10 fine-tuner screws are not arm threads. |
Specification sources
Drawings & installation documents
SchallerSchaller Tremolo (1302)
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent pitch; 54 mm E–e span |
| Mounting / screw / post spacing | Two pivot posts, 74.3 mm centre-to-centre; M7 × 0.5 studs, 10 mm diameter inserts |
| Saddle type | Hardened steel locking saddles |
| Materials | Die-cast zinc baseplate, replaceable hardened steel knife edges, steel saddles/nut, brass block |
| Tremolo arm / thread | Arm assembly supplied; thread pitch not documented in reviewed model source (do not confuse M7 × 0.5 pivot studs or M5 fine-tuners with the arm thread) |
| Radius | 12 inches |
| Fitment / other specifications | 32/37/42 mm block options; 8.5 mm intonation travel; block attachment three screws at 17 mm pitch. Shorter routing envelope than LockMeister; check locking-screw length. |
Specification sources
Drawings & installation documents
SchallerSignum
| Strings | 6 |
|---|---|
| String spacing | 10.5 mm adjacent pitch; 52.5 mm E–e span |
| Mounting / screw / post spacing | Two studs, 81.8 mm centre-to-centre |
| Saddle type | Individually intonated solid brass saddles |
| Materials | Die-cast zinc body; uncoated brass saddles |
| Tremolo arm / thread | Not applicable (fixed bridge) |
| Radius | 12 inches |
| Fitment / other specifications | 9 mm saddle travel; M8 metric or 5/16-24 UNF stud options. Minimum D/G string height 13.2 mm. Left-handed compatible. |
Specification sources
Drawings & installation documents
SchallerSTM
| Strings | 6 |
|---|---|
| String spacing | Adjustable 9.7–11.5 mm adjacent pitch; 48.5–57.5 mm E–e span |
| Mounting / screw / post spacing | Two posts; accommodates 74.0–74.5 mm centre-to-centre |
| Saddle type | Brass rollers: wide flat low-string and U-shaped high-string rollers |
| Materials | Uncoated solid brass rollers/saddles; body alloy not specified in reviewed page |
| Tremolo arm / thread | Not applicable (fixed bridge) |
| Radius | 12–14 inches depending on roller position |
| Fitment / other specifications | M5 stud/insert or M8 stud options. Minimum D/G string height 12.5 mm; maximum string gauge .052 inch. Reverse/non-reverse versions. |
Specification sources
Drawings & installation documents
SchallerVintage Tremolo (roller saddles)
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent pitch (54 ÷ 5); 54 mm E–e span |
| Mounting / screw / post spacing | Two pivot posts, 74.3 mm centre-to-centre; 10 mm diameter inserts |
| Saddle type | Roller saddles |
| Materials | Hardened steel baseplate; brass block; roller alloy not specified in reviewed page |
| Tremolo arm / thread | Arm assembly supplied; thread pitch not documented in reviewed model source (do not confuse M7 × 0.5 pivot studs or M5 fine-tuners with the arm thread) |
| Radius | Not documented in reviewed manufacturer sources |
| Fitment / other specifications | 32/37/42 mm block options; 12 mm intonation travel; block screws 21.5 mm pitch. This is Floyd-style 74.3 mm mounting, not Fender 56 mm two-post mounting. |
Specification sources
Drawings & installation documents
Sophia
Sophia2:22 Deluxe Pro — historical specification
| Strings | 6 |
|---|---|
| String spacing | Not published in the cited historical manufacturer listing |
| Mounting / screw / post spacing | Locking riser posts and inserts; American Standard Strat / Wilkinson-style fit claimed in manufacturer listing |
| Saddle type | Dual-locking stainless steel saddles |
| Materials | Stainless steel saddles; copper-coated springs and claw |
| Tremolo arm / thread | Manufacturer describes wobble-free high-performance arm; diameter/thread not specified |
| Radius | Not published in the cited historical manufacturer listing |
| Fitment / other specifications | Manufacturer-authored 2017 listing. Includes Global Tuner Pro with dual stabilizers. Spring-block choices listed as 32, 37 or 42 mm. Check current variant separately; not a current production specification. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Sophia2:92 S — historical specification
| Strings | 6 |
|---|---|
| String spacing | Not published in the cited historical manufacturer listing |
| Mounting / screw / post spacing | Locking riser posts and inserts; Original Floyd Rose-style compatibility claimed in manufacturer listing |
| Saddle type | Macro-tuners; dual-loading/locking design accepts ball end in tuner knob or plain end through nose slot |
| Materials | Brass and stainless steel Global Tuner; copper-coated springs |
| Tremolo arm / thread | Slip-fit CSL arm; thread not applicable to the slip-fit connection |
| Radius | Not published in the cited historical manufacturer listing |
| Fitment / other specifications | Manufacturer-authored historical listing, describing 2018/2019 version. Global Tuner depths listed as 32, 34, 37 or 42 mm. Listing conflicts on 40:1 versus 60:1 ratio, so ratio is intentionally unverified. Verify exact revision. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Steinberger
SteinbergerR-Trem (Spirit GT-PRO)
| Strings | 6 |
|---|---|
| String spacing | 0.42 in adjacent-string pitch, as specified for the Spirit GT-PRO. E–E span not separately specified. |
| Mounting / screw / post spacing | Not documented in cited sources |
| Saddle type | Steel saddles with bridge-mounted direct-pull tuners. |
| Materials | Steel saddles; other bridge alloys unspecified. |
| Tremolo arm / thread | Not documented in cited sources |
| Radius | Not documented in cited sources |
| Fitment / other specifications | 40:1 direct-pull tuning. R-Trem locks as a fixed bridge or unlocks for floating dives and pull-ups. Factory DoubleBall 10–46 strings; a separate adapter supports regular strings. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
SteinbergerSynapse Piezo Mono-Saddle Bridge
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Not documented in cited sources |
| Saddle type | Single piezo saddle on a lockable base; three upper screws adjust base height and tilt. |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | Not applicable — fixed bridge. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Bow-tie saddle slot permits rotation for outer-string intonation; saddle base position adjusts overall intonation. This is separate from the individual-saddle version. |
Specification sources
Drawings & installation documents
SteinbergerSynapse Standard Individual-Saddle Bridge
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Not documented in cited sources |
| Saddle type | Individually height-adjustable saddles; side set screw locks the saddle assembly. |
| Materials | Not documented in cited sources |
| Tremolo arm / thread | Not applicable — fixed bridge. |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Release the side locking screw before saddle adjustment and re-lock afterwards. Exact hex key size, spacing and alloy not given. |
Specification sources
Drawings & installation documents
Stetsbar
Stetsbar3-Hole
| Strings | 6 |
|---|---|
| String spacing | Not published in the cited source |
| Mounting / screw / post spacing | Three-hole hardtail Strat / Tele Slimline mount |
| Saddle type | Tune-o-matic-type bridge moves with string anchor |
| Materials | Micro-roller bearing linear mechanism; individual alloy specification not published in cited page |
| Tremolo arm / thread | Adjustable arm joint; thread size not published in cited page |
| Radius | Not published in the cited source |
| Fitment / other specifications | Model-specific baseplate is essential. Use fit schematic rather than generic stop-tail measurements. |
Specification sources
Drawings & installation documents
StetsbarStop Tail
| Strings | 6 |
|---|---|
| String spacing | Not published in the cited source |
| Mounting / screw / post spacing | Existing Gibson-style stop-tail bushings; inch and metric bolts supplied |
| Saddle type | Tune-o-matic-type bridge moves with string anchor |
| Materials | Micro-roller bearing linear mechanism; individual alloy specification not published in cited page |
| Tremolo arm / thread | Adjustable arm joint; thread size not published in cited page |
| Radius | Not published in the cited source |
| Fitment / other specifications | Model-specific baseplate is essential. Use fit schematic rather than generic stop-tail measurements. |
Specification sources
Drawings & installation documents
StetsbarT-Style
| Strings | 6 |
|---|---|
| String spacing | Not published in the cited source |
| Mounting / screw / post spacing | Existing ashtray bridge screw holes; supplied neck shim required |
| Saddle type | Tune-o-matic-type bridge moves with string anchor |
| Materials | Micro-roller bearing linear mechanism; individual alloy specification not published in cited page |
| Tremolo arm / thread | Adjustable arm joint; thread size not published in cited page |
| Radius | Not published in the cited source |
| Fitment / other specifications | Model-specific baseplate is essential. Use fit schematic rather than generic stop-tail measurements. |
Specification sources
Drawings & installation documents
StetsbarWrapover G1
| Strings | 6 |
|---|---|
| String spacing | Not published in the cited source |
| Mounting / screw / post spacing | Straight / non-angled wraparound bridge applications |
| Saddle type | Tune-o-matic-type bridge moves with string anchor |
| Materials | Micro-roller bearing linear mechanism; individual alloy specification not published in cited page |
| Tremolo arm / thread | Adjustable arm joint; thread size not published in cited page |
| Radius | Not published in the cited source |
| Fitment / other specifications | Model-specific baseplate is essential. Use fit schematic rather than generic stop-tail measurements. |
Specification sources
Drawings & installation documents
StetsbarWrapover G2
| Strings | 6 |
|---|---|
| String spacing | Not published in the cited source |
| Mounting / screw / post spacing | Angled wraparound bridge applications |
| Saddle type | Tune-o-matic-type bridge moves with string anchor |
| Materials | Micro-roller bearing linear mechanism; individual alloy specification not published in cited page |
| Tremolo arm / thread | Adjustable arm joint; thread size not published in cited page |
| Radius | Not published in the cited source |
| Fitment / other specifications | Model-specific baseplate is essential. Use fit schematic rather than generic stop-tail measurements. |
Specification sources
Drawings & installation documents
Strandberg
StrandbergEGS Rev 7 Tremolo
| Strings | 6 / 7 (guitar dependent) |
|---|---|
| String spacing | Not published in the cited source |
| Mounting / screw / post spacing | Not published in the cited source |
| Saddle type | EGS individual tuner / self-locking saddle modules |
| Materials | Not published in the cited source |
| Tremolo arm / thread | Earlier arm assembly; see revision-specific instructions |
| Radius | Not published in the cited source |
| Fitment / other specifications | Self-locking hex saddle; 4 mm saddle socket, 2 mm tuner mounting screw hex, 6 mm tuner bolt hex. Tool hex sizes are not screw thread sizes. Exact string spacing depends on guitar and must be checked separately. |
Specification sources
Drawings & installation documents
StrandbergEGS Rev 7B Tremolo
| Strings | 6 / 7 (guitar dependent) |
|---|---|
| String spacing | Not published in the cited source |
| Mounting / screw / post spacing | Not published in the cited source |
| Saddle type | EGS individual tuner / self-locking saddle modules |
| Materials | Not published in the cited source |
| Tremolo arm / thread | Click-in arm |
| Radius | Not published in the cited source |
| Fitment / other specifications | Introduced 2024. Bridge and tuners remain as Rev 7, but tremolo arm assembly changed to click-in. Tool hex sizes are not screw thread sizes. Exact string spacing depends on guitar and must be checked separately. |
Specification sources
Drawings & installation documents
Super Vee
Super VeeBladeRunner 2-Point
| Strings | 6 |
|---|---|
| String spacing | 2.1 in E–E |
| Mounting / screw / post spacing | Two-post pivot guitars; select USA/MIM, Asian or Carvin adapter |
| Saddle type | Modern saddles; 2-Point page also lists GraphTech option |
| Materials | Tempered spring-steel flexing blade; Sustainium, bell-brass or carbon-steel block options |
| Tremolo arm / thread | Thread / diameter not published in cited product page |
| Radius | Not published in the cited source |
| Fitment / other specifications | Blade flexes rather than rotating on a rubbing knife edge. Manufacturer compatibility claims still require checking the actual guitar routing and adapter. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Super VeeBladeRunner Standard Mount
| Strings | 6 |
|---|---|
| String spacing | 2.1 in E–E |
| Mounting / screw / post spacing | Vintage six-screw footprint; uses four of the six existing holes |
| Saddle type | Modern saddles; 2-Point page also lists GraphTech option |
| Materials | Tempered spring-steel flexing blade; Sustainium, bell-brass or carbon-steel block options |
| Tremolo arm / thread | Thread / diameter not published in cited product page |
| Radius | Not published in the cited source |
| Fitment / other specifications | Blade flexes rather than rotating on a rubbing knife edge. Manufacturer compatibility claims still require checking the actual guitar routing and adapter. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Trem King
Trem KingTKS-1 / TK-1
| Strings | 6 |
|---|---|
| String spacing | Not published in the cited source |
| Mounting / screw / post spacing | Three #6 × 1-inch countersunk wood screws; original holes plugged; routing required. |
| Saddle type | Fixed saddle bridge; pitch change occurs at moving tone block |
| Materials | Not published in the cited source |
| Tremolo arm / thread | Inserted arm retained by two tone-block set screws; screw-in thread not specified. |
| Radius | Not published in the cited source |
| Fitment / other specifications | Consult installation templates for top and rear cavity. Do not assume six-screw conversion fits without routing. |
Specification sources
Drawings & installation documents
VegaTrem
VegaTremVT1 Ultra Trem 2-points
| Strings | 6 |
|---|---|
| String spacing | 10.7 mm per string; 53.5 mm E–E in official VT1 drawing |
| Mounting / screw / post spacing | Retrofit for two-point vibrato; supplied adapters: American 1/4-28, Asian M6, M7×0.75 (these are mounting adapter threads) |
| Saddle type | Individual height / intonation saddles |
| Materials | Stainless steel construction; manufacturer quality page specifies galvanized steel block |
| Tremolo arm / thread | Receiving bushing requires lubrication; arm thread not published in cited sources |
| Radius | Not published in the cited source |
| Fitment / other specifications | Official VT1 drawing: 76.5 mm overall plate width and 34 mm overall depth. Use exact adapter / fulcrum version for the guitar. |
Specification sources
Drawings & installation documents
VegaTremVT1 Ultra Trem Standard
| Strings | 6 |
|---|---|
| String spacing | 10.7 mm per string; 53.5 mm E–E in official VT1 drawing |
| Mounting / screw / post spacing | Retrofit for traditional six-screw vibrato; uses separate fulcrum |
| Saddle type | Individual height / intonation saddles |
| Materials | Stainless steel construction; manufacturer quality page specifies galvanized steel block |
| Tremolo arm / thread | Receiving bushing requires lubrication; arm thread not published in cited sources |
| Radius | Not published in the cited source |
| Fitment / other specifications | Official VT1 drawing: 76.5 mm overall plate width and 34 mm overall depth. Use exact adapter / fulcrum version for the guitar. |
Specification sources
Drawings & installation documents
VegaTremVT2 Teletrem
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm per string in official VT2 drawing |
| Mounting / screw / post spacing | Tele-style plate; verify full screw and pickup pattern in drawing |
| Saddle type | Brass individual saddles |
| Materials | 316 marine stainless steel fulcrum and 4 mm plate; brass saddles |
| Tremolo arm / thread | Collar-style arm shown; thread size not published |
| Radius | Not published in the cited source |
| Fitment / other specifications | Drawing shows plate 99.30 mm long and 80 mm wide. This is the original VT2 drawing; do not substitute it for VT2ND new-saddle versions. |
Specification sources
Drawings & installation documents
VegaTremVT2ND Teletrem Classic
| Strings | 6 |
|---|---|
| String spacing | Not published in the cited source |
| Mounting / screw / post spacing | 71 mm from string holes to top bridge-pickup screw (manufacturer selection criterion; not post spacing) |
| Saddle type | New patented VT2ND saddle design |
| Materials | Not published in the cited source |
| Tremolo arm / thread | Not published in the cited source |
| Radius | Not published in the cited source |
| Fitment / other specifications | Classic and Modern have different bridge footprints. Do not use the older VT2 drawing as a VT2ND drilling template. |
Specification sources
Drawings & installation documents
VegaTremVT2ND Teletrem Modern
| Strings | 6 |
|---|---|
| String spacing | Not published in the cited source |
| Mounting / screw / post spacing | 66 mm from string holes to top bridge-pickup screw (manufacturer selection criterion; not post spacing) |
| Saddle type | New patented VT2ND saddle design |
| Materials | Not published in the cited source |
| Tremolo arm / thread | Not published in the cited source |
| Radius | Not published in the cited source |
| Fitment / other specifications | Classic and Modern have different bridge footprints. Do not use the older VT2 drawing as a VT2ND drilling template. |
Specification sources
Drawings & installation documents
WD Music
WD MusicWD108 Replacement Hardtail
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm per string; 54 mm E–E. |
| Mounting / screw / post spacing | Three screws; 22.75 mm adjacent centres / 45.50 mm outside centres. |
| Saddle type | Tracked outer saddles; material not stated. |
| Materials | Not documented in the cited manufacturer source. |
| Tremolo arm / thread | Not applicable. |
| Radius | Not documented in the cited manufacturer source. |
| Fitment / other specifications | Plate 41.92 × 75.25 mm. Maker expressly says this is not a direct Stratocaster replacement. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
Wilkinson by Gotoh
Wilkinson by GotohVS100N
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent-string pitch; 54 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Two pivot posts; drawing locates knife contacts at 28.4 mm either side of centre (56.8 mm nominal total); M6 studs, 10 mm diameter inserts |
| Saddle type | Block-style saddles shown in drawing; material not stated |
| Materials | Not documented in reviewed manufacturer sources |
| Tremolo arm / thread | A7, 5.5 mm shaft diameter; thread pitch not specified in reviewed sources |
| Radius | Not documented in reviewed manufacturer sources |
| Fitment / other specifications | Stud-lock system. Use the complete knife-edge drawing to evaluate post compatibility. |
Specification sources
Drawings & installation documents
Wilkinson by GotohVSVG
| Strings | 6 |
|---|---|
| String spacing | 10.8 mm adjacent-string pitch; 54 mm outer-string span (manufacturer drawing) |
| Mounting / screw / post spacing | Six mounting positions: 56 mm outer span, 11.2 mm pitch; one round hole and five elongated holes (manufacturer drawing) |
| Saddle type | Bent-sheet style shown in drawing; material not stated on reviewed product page |
| Materials | Not documented in reviewed manufacturer sources |
| Tremolo arm / thread | AW-2, 5 mm shaft diameter; thread pitch not specified in reviewed sources |
| Radius | Not documented in reviewed manufacturer sources |
| Fitment / other specifications | Not documented in cited sources |
Specification sources
Drawings & installation documents
Yamaha
YamahaVintage Custom Tremolo (Pacifica 904)
| Strings | 6 |
|---|---|
| String spacing | Not documented in cited sources |
| Mounting / screw / post spacing | Two-point fulcrum; exact post centre spacing unspecified. |
| Saddle type | Not documented in cited sources |
| Materials | Steel casting, as described in Yamaha catalog. |
| Tremolo arm / thread | Not documented in cited sources |
| Radius | Not documented in cited sources |
| Fitment / other specifications | Factory Pacifica 904 bridge. The catalog distinguishes it from the Gotoh-built Wilkinson VS100 used on 604W, 812W and 812WX. |
Specification sources
Drawings & installation documents
No drawing located in the cited research.
No models match these filters. Try a shorter search, another brand, or reset the filters.
How to read the measurements
- String pitch
- The centre-to-centre distance between neighbouring strings at the bridge. A string-pitch value is different from the total outer-string spread.
- E–E spacing
- The centre-to-centre distance from the low E to high E on a six-string guitar. Other string counts use their stated outer-string endpoints.
- Post spacing
- Stud or pivot centre-to-centre distance. Screw spacing may mean adjacent screws or the two outer screws; the record preserves the source’s definition.
- Arm thread
- Diameter and pitch must both match. Push-in, collet and threaded designs are distinct. Do not assume the same thread across a brand’s models.
- Undocumented
- “Not documented in cited sources” means the research has not established the value. It is not a zero value or a compatibility claim.
Manufacturer-source reference; verify the exact variant and its dimensioned drawing before drilling or ordering a replacement. Dimensions, routes, arm fittings and hardware can differ by production year, string count and OEM version. Diagrams and manuals open at their original sources.
